Massey Ferguson 4709 – specifications
Built: 2018 · Series: Other models
Data for the version built 2018 · Data origin: Official register, Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 2018
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Massey Ferguson 4709 is a tractor that was introduced into the model range in 2018. As part of the tractor category, this model targets users requiring a compact utility tractor for agricultural or municipal tasks. The design is based on a three-cylinder engine with a displacement of 3,296 cm³, delivering 95 hp at a rated speed of 2,200 rpm. This technical configuration defines the machine's basic profile and sets the framework for its operational capabilities.
In practical use, the 95 hp output enables the handling of medium-duty field work and the operation of various implements. The unladen weight of 3,900 kg ensures stable stability, while the permissible gross weight of 6,200 kg allows for flexible loading with ballast or trailer loads. The Dyna Synchroshift transmission with 12 forward and 12 reverse gears offers a wide spread of gear ratios, which is beneficial for adapting to different speeds for transport and soil cultivation. The maximum speed of 40 km/h is designed for road travel between work sites.
Within the available data, the Massey Ferguson 4709 is positioned as a standalone model. The dimensions, with a length of 4,454 mm and a width of 2,110 mm, along with a wheelbase of 2,250 mm, determine maneuverability and stability on uneven terrain. The fuel tank capacity of 120 l ensures sufficient range for longer work phases without frequent refueling. This combination of weight, power, and transmission tuning defines the typical application range of this tractor class.
Massey Ferguson – other models: collective page of tractors outside the named ranges, from the 100 series to the 8000 series, 22 to 216 kW, Perkins and other diesel engines
This page gathers the Massey Ferguson tractors the register could not assign to a named range, from compact four-cylinder models to large four-wheel-drive tractors of the 8000 class. Massey Ferguson was formed in 1953 from the merger of Massey-Harris with Harry Ferguson's tractor firm and has belonged to AGCO since 1994. The type logic changed several times: three-digit types order size in ascending order, four-digit ranges such as the 4245 or 6480 give the range in the thousands digit and the model in the remaining digits, and the 4X4 suffix marks four-wheel drive. The entry TE-A-20 belongs to the licence-built Ferguson TE-20 from the transitional years after the merger.
Read on 3 more paragraphs
The register lists here 40 versions with 22 to 216 kW from three- to eight-cylinder engines of 1,750 to 10,500 cm³, unladen weights of 1,100 to 9,200 kg, gross weights up to 13,180 kg, lengths of 2,769 to 5,200 mm, widths of 1,500 to 2,720 mm and heights up to 3,200 mm; torque ranges from 176.8 to 593 Nm at rated speeds of 1,600 to 2,250 rpm.
By unit numbers Massey Ferguson is one of the world's best-selling tractor brands, with strongholds in Britain, France and Scandinavia; the models listed here span the full range from yard tractor to large field tractor.
When buying used, on the smaller model years the radiator, head gasket and hydraulic pump matter, on the large 4x4 models the transfer case, front axle and electronics; rust on mudguards and steps is common on older models. Parts run through AGCO and Perkins as well as a broad independent market.
Sources: SpecCodex register, model data: Massey Ferguson (weitere Modelle), Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Power | 95 hp (70 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 3,296 cm³correct |
Dimensions and weights
| Length | 4,454 mmcorrect |
|---|---|
| Width | 2,110 mmcorrect |
| Wheelbase | 2,250 mmcorrect |
| Unladen weight | 3,900 kgcorrect |
| Gross vehicle weight | 6,200 kgcorrect |
Drivetrain and chassis
| Gearbox | Dyna Synchroshift 12/12correct |
|---|---|
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 120 lcorrect |
|---|
Area: Machines
Where this model stands
Power-to-weight ratio: 17.9 kW/t (70 kW / 3.9 t)
Power class: Universal (40–100 hp)
Stronger than 63% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Massey Ferguson 4709 have?
The Massey Ferguson 4709 delivers 95 hp.
How much does the Massey Ferguson 4709 weigh?
The unladen weight is 3,900 kg.
What is the gross vehicle weight of the Massey Ferguson 4709?
6,200 kg.
What engine does the Massey Ferguson 4709 have?
3 cylinders, 3,296 cm³ displacement.
How fast does the Massey Ferguson 4709 go?
Top speed is 40 km/h.
What are the dimensions of the Massey Ferguson 4709?
4,454 mm × 2,110 mm.
When was the Massey Ferguson 4709 built?
Production years: 2018.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
