Sbs Trailers R2 1300 EL – specifications
Built: 2013–2021 · Series: Other models
Data for the version built 2013–2021 · Data origin: Official register · sources
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
SBS Trailers – other models: R2, R4 and R6 boat trailers outside the named ranges, Boottransporter and Bunk versions, 275 to 1,300 kg unladen weight, up to 3,500 kg gross weight
This page gathers the boat trailers from SBS Trailers that the register could not assign to the named R2, R4 or R6 ranges. The model names spell out the type of construction directly: Boottransporter for straightforward transport, Bunk Trailer with beams supporting the hull instead of rollers, and Easy Load Trailer with a low, tiltable frame for easy launching. The type designation itself combines the range (R2 for smaller, R4 for medium, R6 for larger trailers) with the load capacity in kilograms and a suffix for the version, such as EL for the Easy Load variant or B for the Bunk version.
Read on 3 more paragraphs
The register lists here 31 versions with unladen weights from 275 to 1,300 kg and gross weights from 1,000 to 3,500 kg. Lengths range from 6,000 to 8,500 mm, widths from 2,020 to 2,530 mm.
Boat trailers of this size carry motor yachts, sailing boats with a fixed keel or larger rowing boats and usually come with a braked axle once the gross weight exceeds 750 kg. The market for specialised boat trailers is broad across Europe's coastal and lake regions, with an overrun brake, a galvanised frame and either keel rollers or bunk beams depending on hull shape.
When buying used, the condition of the galvanising and the rollers or bunk beams, the function of the overrun brake including the handbrake cable, axle alignment and the seal of the wheel bearings, which see extra wear from frequent water contact, matter most. Spares such as rollers, ball bearings and lighting are available through the general trailer trade.
Sources: SpecCodex register, model data: SBS Trailers (weitere Modelle), Zulassungsdaten RDW (Niederlande)
Technical data
Dimensions and weights
| Length | 6,150 mmcorrect |
|---|---|
| Width | 2,200 mmcorrect |
| Coupling-to-axle distance | 4,670 mmcorrect |
| Gross vehicle weight | 1,300 kgcorrect |
Drivetrain and chassis
| Wheels | 2correct |
|---|---|
| Top speed | 120 km/hcorrect |
Frequently asked questions
What is the gross vehicle weight of the Sbs Trailers R2 1300 EL?
1,300 kg.
Up to what speed is the Sbs Trailers R2 1300 EL approved?
Approved up to 120 km/h.
What are the dimensions of the Sbs Trailers R2 1300 EL?
6,150 mm × 2,200 mm.
When was the Sbs Trailers R2 1300 EL built?
Production years: 2013–2021.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
