Btk 8500 – specifications
Built: 2009 · Series: Other models
Data for the version built 2009 · Data origin: Official register · sources
More machines from model year 2009
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Btk 8500 – class O3 trailer: 8,500 kg gross weight, 2,800 kg unladen weight, 5,700 kg payload, 6,880 mm length, 1,000 mm wheelbase, model year 2009
With a gross weight of 8,500 kg, the 8500 falls into EU class O3, the medium-weight trailers between 3.5 and 10 tonnes. The trailer is registered in the Netherlands and was built in 2009.
Read on 3 more paragraphs
At a length of 6,880 mm and a width of 2,550 mm, it weighs 2,800 kg unladen and carries 5,700 kg of payload, a good two-thirds of its gross weight. The very short wheelbase of just 1,000 mm against a length of 6,880 mm shows that the axles sit close together under the centre of the body rather than spread towards the front and rear – the layout of a centre-axle trailer, which carries its load over its own axle group instead of on a coupling at the front.
From 3.5 tonnes gross weight, EU rules require an air-brake system; the simple overrun brake of classes O1 and O2 is no longer sufficient. Centre-axle trailers of this weight class load the tow vehicle's coupling much less than a drawbar trailer with a front axle and therefore track more calmly. Towing it requires a category BE or C1E/CE licence, depending on the permitted gross combination weight.
On a used example, what counts is the condition of the closely spaced axle group and its bearings, the state of the brake drums or discs and the air system, the tightness of the load platform, and rust on the side members, which are particularly stressed by the short wheelbase and central load distribution. On a centre-axle trailer it is also worth checking even loading, since incorrect load distribution directly changes the nose weight on the coupling.
Sources: SpecCodex-Register: Kennwerte des Modells Btk 8500
Versions of this model in the register
Each row is a separate entry with its own data. The figures on this page belong to the row marked ●.
| Version | Built | kW | EU type approval | Origin |
|---|---|---|---|---|
| ● BTK 8500 | 2009 | — | — | Official register |
| 8500 | 2009 | — | — | Official register |
Technical data
Dimensions and weights
| Length | 6,880 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Coupling-to-axle distance | 1,000 mmcorrect |
| Unladen weight | 2,800 kgcorrect |
| Gross vehicle weight | 8,500 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Btk 8500 weigh?
The unladen weight is 2,800 kg.
What is the gross vehicle weight of the Btk 8500?
8,500 kg.
Up to what speed is the Btk 8500 approved?
Approved up to 100 km/h.
What are the dimensions of the Btk 8500?
6,880 mm × 2,550 mm.
When was the Btk 8500 built?
Production years: 2009.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
