Alois Hieble 824 JD – specifications
Built: 2012 · Series: Bergmeister
The Alois Hieble 824 JD is a model in the Bergmeister series. Production: 2012. The engine delivers 82 hp (60 kW), has 4 cylinders, with a displacement of 4,523 cm³. Rated speed is 2,300 rpm. The machine is 3,320 mm long, 1,200 mm wide and 2,300 mm high. The unladen weight is 2,350 kg. The wheelbase measures 2,040 mm. Ground clearance is 300 mm. Top speed is 40 km/h. The engine is water-cooled. Tyres: front 260/70 R 16, rear 320/85 R 24. The fuel is diesel. The Bergmeister series covers 7 models. Rated output within it ranges from 72 to 86 hp; the 824 JD sits in the upper part of that range with 82 hp. Its immediate neighbours are the 824 CP below it with 79 hp and the 854 above it with 86 hp. Unladen weight within it ranges from 2,060 to 2,350 kg; here the 824 JD sits at the top of that range with 2,350 kg. 9 Alois Hieble models across 2 series are on record.
Data for the version built 2012 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hieble Bergmeister 734 to 854 – the narrow-track tractors of the small Allgäu maker: the first digit as power step, JD and CP as engine variants, three- and four-cylinder diesels of 2.9 to 4.5 litres, 0.98 to 1.20 m wide
The Bergmeister is a small-series narrow-track tractor – built by Alois Hieble, one of the southern German farm-machinery builders who make tractors for hop gardens, vineyards and orchards where at about one metre wide no standard tractor fits any more and the big makers offer only a few models. The type logic: the three-digit number orders the power step – 734 and 754 about 72 to 75 hp, 824 and 854 about 80 to 82 hp – JD marks, by maker's logic, the version with John Deere engine, CP a further engine or equipment variant. The engines are bought-in three- and four-cylinder diesels of 2.9 to 4.5 litres at 2,200 to 2,400 rpm, as small makers source from John Deere, Perkins or Deutz; the rest of the machine – frame, four-wheel-drive axles, cab – is hand-built to customer order with track widths and mounting spaces to row width.
Read on 3 more paragraphs
The register lists 7 versions with 53 to 63 kW from three- and four-cylinders of 2,940 to 4,523 cm³, unladen weights from 2,060 to 2,350 kg, lengths from 3,170 to 3,320 mm, widths from 980 to 1,200 mm and heights from 2,180 to 2,300 mm.
The Bergmeister stands in a row with Krieger, Holder and Fendt's 200 V/F as the narrow-track tractor of the Hallertau and the wine regions; its argument is adaptation to the farm, its drawback the small production run.
On used tractors, operating hours, engine condition (parts through the engine maker), clutch and shuttle, four-wheel-drive axles and steering, PTO and hydraulics for sprayer and mulcher and parts supply for frame and cab, which depends on the maker, count.
Sources: SpecCodex register, model data: Hieble Bergmeister
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 82 hp (60 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,523 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,320 mmcorrect |
|---|---|
| Width | 1,200 mmcorrect |
| Height | 2,300 mmcorrect |
| Wheelbase | 2,040 mmcorrect |
| Ground clearance | 300 mmcorrect |
| Unladen weight | 2,350 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 12/12-Vollsynchrongetriebecorrect |
| Front tyres | 260/70 R 16correct |
| Rear tyres | 320/85 R 24correct |
| Top speed | 40 km/hcorrect |
Frequently asked questions
Where this model stands
Power-to-weight ratio: 25.5 kW/t (60 kW / 2.4 t)
Power class: Universal (40–100 hp)
Stronger than 56% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
