Allis Gleaner Corporation LT-75

Built: 2004–2006 · Series: LT-Serie

More machines from model year 2004

The photo shows the LT-90 from the same series. Source: masseyferguson.com

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The LT series from Allis Gleaner Corporation includes the LT-75. Production: 2004–2006. The engine delivers 78 hp (57.4 kW), has 4 cylinders, with a displacement of 4,484 cm³. Torque is 326 Nm. Rated speed is 2,200 rpm. The machine is 4,204 mm long, 2,108 mm wide and 2,794 mm high. The unladen weight is 4,198 kg. The wheelbase measures 2,464 mm. Top speed is 40 km/h. Transmission: 16 V/16 R. The engine is water-cooled. Tyres: front 11.00-16 ASF (4 WD: 14.9 R 24 AS), rear 18.4 R 34 AS. The fuel is diesel. The bore measures 103.99 mm. The stroke is 132 mm. The compression ratio is 17.5:1. Maximum torque is reached at 1,650 rpm. Construction: unit construction (no separate frame). The LT-Serie series covers 4 models. Rated output within it ranges from 71 to 88 hp; the LT-75 sits in the middle of that range with 78 hp. Its immediate neighbours are the LT-70 below it with 71 hp and the LT-85 above it with 87 hp. Unladen weight within it ranges from 3,697 to 4,198 kg; here the LT-75 sits at the top of that range with 4,198 kg. 8 Allis Gleaner Corporation models across 2 series are on record.

Allis-Gleaner Corporation (AGCO) LT series – LT-70 to LT-90: the mid-size utility tractors after Deutz-Allis, 52 to 65 kW

The LT series held the mid-size utility-tractor class at the Allis-Gleaner Corporation (AGCO), between the compact GT and the big DT series: the LT-70, LT-75, LT-85 and LT-90 with four-cylinder diesel engines. The Allis-Gleaner Corporation emerged in 1990 from the management buyout of the farm-equipment division of Klöckner-Humboldt-Deutz, previously Deutz-Allis, becoming the foundation of today's AGCO group, headquartered in Duluth, Georgia.

Read on 3 more paragraphs

The register lists here 4 versions with 52.2 to 64.7 kW from four-cylinders of 3,927 to 4,484 cm³ displacement, torque from 319 to 436 Nm at 2,200 rpm, unladen weights from 3,697 to 4,198 kg, lengths from 4,191 to 4,204 mm, a width of 2,108 mm and heights from 2,616 to 2,794 mm – all with diesel engines.

As a mid-size class, the LT series covered the broad field of mixed farm work, from forage production to lighter fieldwork, making it the most sought-after size class for family farms combining livestock and arable work across a wide range of regions.

Used, the LT series calls for checking engine condition and the cooling system, clutch and synchromesh gearbox, hydraulics and PTO for mounted implements, and front axle and steering geometry; brakes, electrics and cab seals should also be inspected. Spare parts run through the AGCO organisation.

Sources: SpecCodex register, model data: Allis-Gleaner Corporation LT-Serie, AGCO Corporation

Technical data

Engine

Fuel	dieselcorrect
Power	78 hp (57.4 kW)correct
Rated speed	2,200 rpmcorrect
Torque	326 Nmcorrect
Speed at max. torque	1,650 rpmcorrect
Cylinders	4correct
Displacement	4,484 cm³correct
Bore	103.99 mmcorrect
Stroke	132 mmcorrect
Compression ratio	17.5correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	4,204 mmcorrect
Width	2,108 mmcorrect
Height	2,794 mmcorrect
Wheelbase	2,464 mmcorrect
Unladen weight	4,198 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	16 V/16 Rcorrect
Front tyres	11.00-16 ASF (4 WD: 14.9 R 24 AS)correct
Rear tyres	18.4 R 34 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 13.7 kW/t (57 kW / 4.2 t)

Power class: Universal (40–100 hp)

Stronger than 54% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Allis Gleaner Corporation LT-75 have?

The Allis Gleaner Corporation LT-75 delivers 78 hp.

How much does the Allis Gleaner Corporation LT-75 weigh?

The unladen weight is 4,198 kg.

What engine does the Allis Gleaner Corporation LT-75 have?

4 cylinders, 4,484 cm³ displacement, Diesel.

How fast does the Allis Gleaner Corporation LT-75 go?

Top speed is 40 km/h.

What are the dimensions of the Allis Gleaner Corporation LT-75?

4,204 mm × 2,108 mm × 2,794 mm.

When was the Allis Gleaner Corporation LT-75 built?

Production years: 2004–2006.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
