Start › Tractors › Allis Gleaner Corporation › GT series › GT-55

Allis Gleaner Corporation GT-55

Built: 2004–2007 · Series: GT-Baureihe

More machines from model year 2004

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Allis Gleaner Corporation GT-55 belongs to the GT series. Production: 2004–2007. The engine delivers 67 hp (49.3 kW), has 3 cylinders, with a displacement of 2,999 cm³. Torque is 250 Nm. Rated speed is 2,200 rpm. The machine is 3,720 mm long, 1,920 mm wide and 2,657 mm high. The unladen weight is 2,499 kg. The wheelbase measures 2,105 mm. Ground clearance is 445 mm. Top speed is 40 km/h. Transmission: 16 V/8 R. The engine is air-cooled. Tyres: front 7.50-16 ASF (4 WD: 320/70 R 20 AS), rear 420/70 R 28 AS. The fuel is diesel. The bore measures 105 mm. The stroke is 115.5 mm. The compression ratio is 16:1. Maximum torque is reached at 1,349 rpm. Injection pressure is 180 bar. The GT-Baureihe series covers 4 models. Rated output within it ranges from 52 to 83 hp; the GT-55 sits in the middle of that range with 67 hp. Its immediate neighbours are the GT-45 below it with 52 hp and the GT-65 above it with 71 hp. Unladen weight within it ranges from 2,419 to 2,739 kg; here the GT-55 sits in the lower part of that range with 2,499 kg. 40 Allis Gleaner Corporation models across 9 series are on record.

Allis-Gleaner Corporation (AGCO) GT series – GT-45 to GT-75: the compact utility tractors after Deutz-Allis, 38 to 61 kW

The GT series covered the compact utility-tractor class at the Allis-Gleaner Corporation (AGCO): the GT-45, GT-55, GT-65 and GT-75 with three- and four-cylinder diesel engines, whose type numbers give the approximate power step. The Allis-Gleaner Corporation emerged in 1990 from the management buyout of the farm-equipment division of Klöckner-Humboldt-Deutz, previously Deutz-Allis, laying the foundation of today's AGCO group.

Read on 3 more paragraphs

The register lists here 4 versions with 38.2 to 61 kW from three- and four-cylinders of 2,999 to 3,999 cm³ displacement, torque from 205 to 321 Nm at 2,200 rpm, unladen weights from 2,419 to 2,739 kg, lengths from 3,701 to 3,851 mm, widths from 1,788 to 1,948 mm and heights from 2,631 to 2,692 mm – all with diesel engines.

As a smaller series alongside the big DT standard tractors, the GT series targeted mixed farms and grassland operations with lower power needs, where manoeuvrability and lower weight mattered more than on the heavy field tractors, for instance in feeding or yard transport.

Used, the GT series calls for checking engine condition and the injection pump, clutch and transmission under frequent front-loader work, hydraulics and PTO, and front axle and steering; brakes and cab seals are also worth checking. Spare parts run through the AGCO organisation.

Sources: SpecCodex register, model data: Allis-Gleaner Corporation GT-Baureihe, AGCO Corporation

Technical data

Engine

Fuel	dieselcorrect
Power	67 hp (49.3 kW)correct
Rated speed	2,200 rpmcorrect
Torque	250 Nmcorrect
Speed at max. torque	1,349 rpmcorrect
Cylinders	3correct
Displacement	2,999 cm³correct
Bore	105 mmcorrect
Stroke	115.5 mmcorrect
Compression ratio	16correct
Injection pressure	180 barcorrect
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,720 mmcorrect
Width	1,920 mmcorrect
Height	2,657 mmcorrect
Wheelbase	2,105 mmcorrect
Ground clearance	445 mmcorrect
Unladen weight	2,499 kgcorrect

Drivetrain and chassis

Drive	rear- and four-wheel drivecorrect
Gearbox	16 V/8 Rcorrect
Front tyres	7.50-16 ASF (4 WD: 320/70 R 20 AS)correct
Rear tyres	420/70 R 28 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 19.7 kW/t (49 kW / 2.5 t)

Power class: Universal (40–100 hp)

Stronger than 46% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Allis Gleaner Corporation GT-55 have?

The Allis Gleaner Corporation GT-55 delivers 67 hp.

How much does the Allis Gleaner Corporation GT-55 weigh?

The unladen weight is 2,499 kg.

What engine does the Allis Gleaner Corporation GT-55 have?

3 cylinders, 2,999 cm³ displacement, Diesel.

How fast does the Allis Gleaner Corporation GT-55 go?

Top speed is 40 km/h.

What are the dimensions of the Allis Gleaner Corporation GT-55?

3,720 mm × 1,920 mm × 2,657 mm.

When was the Allis Gleaner Corporation GT-55 built?

Production years: 2004–2007.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
