Allis Gleaner Corporation DT-220 A

Built: 2005–2008 · Series: DTA - Baureihe

More machines from model year 2005

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The DT-220 A from Allis Gleaner Corporation is part of the DTA series. Production: 2005–2008. The engine delivers 260 hp (191.2 kW), has 6 cylinders, with a displacement of 8,419 cm³. Torque is 1,035 Nm. Rated speed is 2,200 rpm. The machine is 5,320 mm long, 2,550 mm wide and 3,180 mm high. The unladen weight is 9,240 kg. The wheelbase measures 3,075 mm. Ground clearance is 500 mm. Top speed is 40 km/h. Transmission: continuously variable. The engine is water-cooled. Tyres: front 600/70 R 28 AS, rear 650/85 R 38 AS. The fuel is diesel. The bore measures 111 mm. The stroke is 145 mm. Maximum torque is reached at 1,499 rpm. The DTA - Baureihe series covers 4 models. Rated output within it ranges from 215 to 290 hp; the DT-220 A sits in the upper part of that range with 260 hp. Its immediate neighbours are the DT-200 A below it with 235 hp and the DT-240 A above it with 290 hp. Unladen weight within it ranges from 8,680 to 9,240 kg; here the DT-220 A sits at the top of that range with 9,240 kg. 40 Allis Gleaner Corporation models across 9 series are on record.

Allis-Gleaner Corporation (AGCO) DTA series – DT-180 A to DT-240 A: the stronger step above the DT series, 158 to 213 kW, up to 9.2 t

The DTA series carried on the Allis-Gleaner Corporation (AGCO) big standard tractors in a stronger-rated step: the DT-180 A, DT-200 A, DT-220 A and DT-240 A sit above the plain DT models in power. The Allis-Gleaner Corporation emerged in 1990 from the management buyout of the farm-equipment division of Klöckner-Humboldt-Deutz, which had previously traded as Deutz-Allis, laying the foundation of today's AGCO group.

Read on 3 more paragraphs

The register lists here 4 versions with 158.1 to 213.3 kW from six-cylinders of 7,365 to 8,419 cm³ displacement, torque from 875 to 1,103 Nm at 2,200 rpm, unladen weights from 8,680 to 9,240 kg, lengths from 5,240 to 5,320 mm, a width of 2,550 mm and heights from 3,090 to 3,180 mm – all with diesel engines.

With higher power and greater weight than the plain DT series, the DTA series covered the upper segment of heavy standard tractors as used on large North American arable operations for primary tillage and heavy mounted implements, competing with the corresponding large models from Case IH and John Deere.

Used, the DTA series calls for checking engine output under full load, turbocharger and charge-air cooling, transmission and axle drive in the heavier weight classes, and the hydraulics and PTO; frame and front-axle bearings should be checked for wear. Spare parts run through the AGCO organisation.

Sources: SpecCodex register, model data: Allis-Gleaner Corporation DTA-Baureihe, AGCO Corporation

Technical data

Engine

Fuel	dieselcorrect
Power	260 hp (191.2 kW)correct
Rated speed	2,200 rpmcorrect
Torque	1,035 Nmcorrect
Speed at max. torque	1,499 rpmcorrect
Cylinders	6correct
Displacement	8,419 cm³correct
Bore	111 mmcorrect
Stroke	145 mmcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	5,320 mmcorrect
Width	2,550 mmcorrect
Height	3,180 mmcorrect
Wheelbase	3,075 mmcorrect
Ground clearance	500 mmcorrect
Unladen weight	9,240 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	continuously variablecorrect
Front tyres	600/70 R 28 AScorrect
Rear tyres	650/85 R 38 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 20.7 kW/t (191 kW / 9.2 t)

Power class: Heavy (> 180 hp)

Stronger than 95% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Allis Gleaner Corporation DT-220 A have?

The Allis Gleaner Corporation DT-220 A delivers 260 hp.

How much does the Allis Gleaner Corporation DT-220 A weigh?

The unladen weight is 9,240 kg.

What engine does the Allis Gleaner Corporation DT-220 A have?

6 cylinders, 8,419 cm³ displacement, Diesel.

How fast does the Allis Gleaner Corporation DT-220 A go?

Top speed is 40 km/h.

What are the dimensions of the Allis Gleaner Corporation DT-220 A?

5,320 mm × 2,550 mm × 3,180 mm.

When was the Allis Gleaner Corporation DT-220 A built?

Production years: 2005–2008.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.
