Start › Tractors › Allis Gleaner Corporation › DT series › DT - 200

Allis Gleaner Corporation DT - 200

Built: 2002–2004 · Series: DT - Baureihe

More machines from model year 2002

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Allis Gleaner Corporation DT - 200 belongs to the DT series. Production: 2002–2004. The engine delivers 203 hp (149.3 kW), has 6 cylinders, with a displacement of 8,268 cm³. Torque is 970 Nm. Rated speed is 2,200 rpm. The machine is 5,156 mm long, 2,494 mm wide and 3,073 mm high. The unladen weight is 8,904 kg. The wheelbase measures 3,073 mm. Ground clearance is 445 mm. Top speed is 40 km/h. Transmission: 18 V/6 R. The engine is water-cooled. Tyres: front 16.9 R 30 AS, rear 20.8 R 42 AS. The fuel is diesel. The bore measures 114 mm. The stroke is 135 mm. The compression ratio is 17.3:1. Maximum torque is reached at 1,300 rpm. The DT - Baureihe series covers 4 models. Rated output within it ranges from 162 to 228 hp; the DT - 200 sits in the upper part of that range with 203 hp. Its immediate neighbours are the DT - 180 below it with 182 hp and the DT - 225 above it with 228 hp. Unladen weight within it ranges from 8,623 to 8,956 kg; here the DT - 200 sits in the upper part of that range with 8,904 kg. 40 Allis Gleaner Corporation models across 9 series are on record.

Allis-Gleaner Corporation (AGCO) DT series – DT-160 to DT-225: the big six-cylinder standard tractors after Deutz-Allis, 119 to 168 kW

The DT series held the place of the big field-tractor class in the Allis-Gleaner Corporation (AGCO) line-up: four six-cylinder diesel types from the DT-160 to the DT-225, whose type numbers give the approximate power step. The Allis-Gleaner Corporation was formed in 1990 from a management buyout of the farm-equipment division of Klöckner-Humboldt-Deutz, which had previously traded as Deutz-Allis, and became the foundation of today's AGCO group, headquartered in Duluth, Georgia.

Read on 3 more paragraphs

The register lists here 4 versions with 119.2 to 167.7 kW from six-cylinders of 8,268 cm³ displacement, torque from 729 to 970 Nm at 2,200 rpm, unladen weights from 8,623 to 8,956 kg and uniform dimensions of 5,156 mm length, 2,494 mm width and 3,073 mm height – all with diesel engines.

As big standard tractors of the Deutz-Allis and AGCO-Allis era, the DT series targeted operations with high draft requirements in field work and competed in the North American market directly with the big models from Case IH and John Deere as well as with AGCO's own brands.

Used, the DT series calls for checking engine hours and the cooling system, transmission and clutch under full load, hydraulic pump and PTO for heavy mounted implements, and frame and front-axle bearings; cab electrics and tyres are also worth checking. Spare parts now run through the AGCO organisation.

Sources: SpecCodex register, model data: Allis-Gleaner Corporation DT-Baureihe, AGCO Corporation

Technical data

Engine

Fuel	dieselcorrect
Power	203 hp (149.3 kW)correct
Rated speed	2,200 rpmcorrect
Torque	970 Nmcorrect
Speed at max. torque	1,300 rpmcorrect
Cylinders	6correct
Displacement	8,268 cm³correct
Bore	114 mmcorrect
Stroke	135 mmcorrect
Compression ratio	17.3correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	5,156 mmcorrect
Width	2,494 mmcorrect
Height	3,073 mmcorrect
Wheelbase	3,073 mmcorrect
Ground clearance	445 mmcorrect
Unladen weight	8,904 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	18 V/6 Rcorrect
Front tyres	16.9 R 30 AScorrect
Rear tyres	20.8 R 42 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 16.8 kW/t (149 kW / 8.9 t)

Power class: Heavy (> 180 hp)

Stronger than 91% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Allis Gleaner Corporation DT - 200 have?

The Allis Gleaner Corporation DT - 200 delivers 203 hp.

How much does the Allis Gleaner Corporation DT - 200 weigh?

The unladen weight is 8,904 kg.

What engine does the Allis Gleaner Corporation DT - 200 have?

6 cylinders, 8,268 cm³ displacement, Diesel.

How fast does the Allis Gleaner Corporation DT - 200 go?

Top speed is 40 km/h.

What are the dimensions of the Allis Gleaner Corporation DT - 200?

5,156 mm × 2,494 mm × 3,073 mm.

When was the Allis Gleaner Corporation DT - 200 built?

Production years: 2002–2004.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
