Agrifull C 80-60
Built: 1980–1986 · Series: C - Baureihe
More machines from model year 1980
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Agrifull C series (1980s) – the crawler tractors of the Fiat subsidiary from Modena: 355-C to C 80-70, the number as hp class, C for Cingolato, Special as equipment, three- and four-cylinders of 2.6 to 3.5 litres
The C series was the crawler-tractor programme of Agrifull, the Fiat subsidiary from Modena that sold specialist and compact tractors alongside the Fiat tractors from Turin in the 1980s – crawler tractors for vineyard, orchard and slope, as have carried the farming of Italy's hill and mountain regions since the 1930s, where the wheeled tractor slips in the dry and tips on the slope. The type logic: C stands for Cingolato, the crawler tractor, the number gives the hp class – C 60 about 60 hp, C-70 70 hp, the double numbers C 80-50 to C 80-70 the 80 range with 50 to 70 hp – Special an equipment variant, the 355-C the version with 55 hp and three-cylinder. The engines are Fiat's three- and four-cylinder diesels of 2.6 to 3.5 litres at 2,300 to 2,600 rpm; the machines are low, built at 1.07 to 1.33 metres high to pass under vine rows and fruit trees.
Read on 3 more paragraphs
The register lists 6 versions with 36.8 to 48.5 kW from three- and four-cylinders of 2,592 to 3,456 cm³, torque from 172 to 220 Nm, unladen weights from 2,410 to 3,200 kg, lengths from 2,200 to 2,850 mm, widths from 1,147 to 1,680 mm and heights from 1,070 to 1,330 mm.
The crawler tractor has remained an Italian speciality: Fiat and Agrifull were the largest makers, today New Holland (TK) and Landini continue the class in which Italy sets the world market.
On used tractors, operating hours, the condition of undercarriage (tracks, rollers, sprockets – the most expensive item), steering clutches and brakes, engine and injection pump, PTO and hydraulics count; parts run through New Holland and Italian crawler specialists.
Sources: SpecCodex register, model data: Agrifull C-Baureihe, Fiat Trattori (Wikipedia)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 55 hp (40.5 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,592 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 110 mmcorrect |
| Compression ratio | 17correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,545 mmcorrect |
|---|---|
| Width | 1,440 mmcorrect |
| Height | 1,260 mmcorrect |
| Wheelbase | 1,300 mmcorrect |
| Ground clearance | 240 mmcorrect |
| Unladen weight | 2,810 kgcorrect |
Drivetrain and chassis
| Drive | chain drivecorrect |
|---|---|
| Gearbox | 6 V/2 Rcorrect |
| Forward gears | 6correct |
| Reverse gears | 2correct |
| Front tyres | 310correct |
| Rear tyres | 310correct |
| Top speed | 12 km/hcorrect |
Working data
| Fuel tank capacity | 60 lcorrect |
|---|
Origin and approval
| Construction | frame constructioncorrect |
|---|
Where this model stands
Power-to-weight ratio: 14.4 kW/t (40 kW / 2.8 t)
Power class: Universal (40–100 hp)
Stronger than 38% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Agrifull C 80-60 have?
The Agrifull C 80-60 delivers 55 hp.
How much does the Agrifull C 80-60 weigh?
The unladen weight is 2,810 kg.
What engine does the Agrifull C 80-60 have?
3 cylinders, 2,592 cm³ displacement, Diesel.
How fast does the Agrifull C 80-60 go?
Top speed is 12 km/h.
What are the dimensions of the Agrifull C 80-60?
2,545 mm × 1,440 mm × 1,260 mm.
When was the Agrifull C 80-60 built?
Production years: 1980–1986.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 26 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Sources: Wikibooks Traktorenlexikon (CC BY-SA 4.0) (retrieved August 2026) · How we check the data
Tractor in 3D section
Turn the model, look inside and click an assembly — each one is explained.
