Agrifull A-50 (DT)

Built: 1991–1993 · Series: A-Baureihe

More machines from model year 1991

Source: https://www.truck1.eu/agricultural-machinery/farm-tractors/f

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The A series from Agrifull includes the A-50 (DT). Production: 1991–1993. The engine delivers 50 hp (36.8 kW), has 3 cylinders, with a displacement of 2,710 cm³. Torque is 155 Nm. Rated speed is 2,500 rpm. The machine is 2,976 mm long, 1,540 mm wide and 2,245 mm high. The unladen weight is 2,125 kg. The wheelbase measures 1,999 mm. Ground clearance is 445 mm. Top speed is 30 km/h. Transmission: 12 V/4 R, 12 V/12 R and 20 V/8 R. The engine is water-cooled. Tyres: front 5.50-16 ASF (DT: 7.50-20 AS), rear 12.4-28 AS. The fuel is diesel. The bore measures 100 mm. The stroke is 115 mm. The compression ratio is 17:1. Maximum torque is reached at 1,200 rpm. Construction: frame construction. Injection pressure is 230 bar. Rated output across the Agrifull range ranges from 30 to 140 hp; the A-50 (DT) sits in the lower part of that range with 50 hp. Its immediate neighbours are the 80-50 (DT) below it with 48 hp and the 60 DT above it with 54 hp. Rated output across the Agrifull range ranges from 22.1 to 103 kW; here the A-50 (DT) sits in the lower part of that range with 36.8 kW. 68 Agrifull models across 10 series are on record.

Agrifull A series (A-50, A-140 DT Turbo) – wide power span from three-cylinder to turbo six-cylinder: 36.8 to 103 kW, 2,710 to 5,861 cm³ displacement, 2,125 to 6,800 kg unladen weight

The Agrifull A series from the Italian Fiat group covered, under the shared A letter code, a wide span of standard tractors, from light three-cylinder models such as the A-50 to the turbocharged six-cylinder A-140 DT Turbo at the top of the range; DT, as in the 10 series, marks four-wheel drive.

Read on 3 more paragraphs

The register lists here 2 versions with 36.8 to 103 kW from three- to six-cylinders of 2,710 to 5,861 cm³ displacement, unladen weights from 2,125 to 6,800 kg, a length of 2,976 to 4,180 mm, a width of 1,540 to 2,400 mm, a height of 2,245 to 2,830 mm, and torque of 155 to 465 Nm at 2,500 rpm.

With this span from small general-purpose machine to large turbo tractor, the A series covered almost the whole market segment in which Agrifull competed within the Fiat group alongside Fiat's own, more broadly based standard tractors. Among collectors, Fiat-group tractors both narrow and standard in track, such as the Agrifull A series, are regarded today as sought-after youngtimers.

On used A-series tractors, what counts varies by model: on the small A-50 mainly clutch and gearbox, on the A-140 DT Turbo additionally the condition of the turbocharger, front-axle drive clutch and injection system, and rust on mudguards and frame; parts run through dealers specialising in Fiat/Agrifull. and the wiring.

Sources: SpecCodex register, model data: Agrifull A-Baureihe

Technical data

Engine

Fuel	dieselcorrect
Power	50 hp (36.8 kW)correct
Rated speed	2,500 rpmcorrect
Torque	155 Nmcorrect
Speed at max. torque	1,200 rpmcorrect
Cylinders	3correct
Displacement	2,710 cm³correct
Bore	100 mmcorrect
Stroke	115 mmcorrect
Compression ratio	17correct
Injection pressure	230 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	2,976 mmcorrect
Width	1,540 mmcorrect
Height	2,245 mmcorrect
Wheelbase	1,999 mmcorrect
Ground clearance	445 mmcorrect
Unladen weight	2,125 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	12 V/4 R, 12 V/12 R and 20 V/8 Rcorrect
Front tyres	5.50-16 ASF (DT: 7.50-20 AS)correct
Rear tyres	12.4-28 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	frame constructioncorrect

Where this model stands

Power-to-weight ratio: 17.3 kW/t (37 kW / 2.1 t)

Power class: Universal (40–100 hp)

Stronger than 34% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Agrifull A-50 (DT) have?

The Agrifull A-50 (DT) delivers 50 hp.

How much does the Agrifull A-50 (DT) weigh?

The unladen weight is 2,125 kg.

What engine does the Agrifull A-50 (DT) have?

3 cylinders, 2,710 cm³ displacement, Diesel.

How fast does the Agrifull A-50 (DT) go?

Top speed is 30 km/h.

What are the dimensions of the Agrifull A-50 (DT)?

2,976 mm × 1,540 mm × 2,245 mm.

When was the Agrifull A-50 (DT) built?

Production years: 1991–1993.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
