Start › Tractors › Agrifull › 10 er - Baureihe › 60 DT

Agrifull 60 DT

Built: 1976–1977 · Series: 10 er - Baureihe

More machines from model year 1976

Source: https://www.technikboerse.com/gebraucht/traktor-357/deutz-fa

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 10er series from Agrifull includes the 60 DT. Production: 1976–1977. The engine delivers 54 hp (39.7 kW), has 3 cylinders, with a displacement of 2,856 cm³. Torque is 172 Nm. Rated speed is 2,300 rpm. The machine is 3,650 mm long, 1,740 mm wide and 2,380 mm high. The unladen weight is 2,280 kg. The wheelbase measures 2,145 mm. Ground clearance is 330 mm. Top speed is 25 km/h. Transmission: 8 V/4 R. The engine is air-cooled. Tyres: front 6.00-16 ASF (DT: 9.5-20 AS), rear 13.6-28 AS. The fuel is diesel. The bore measures 105 mm. The stroke is 110 mm. Maximum torque is reached at 1,700 rpm. Construction: frame construction. Injection pressure is 176 bar. Rated output across the Agrifull range ranges from 30 to 140 hp; the 60 DT sits in the lower part of that range with 54 hp. Its immediate neighbours are the C 80-50 below it with 50 hp and the 350-C (CL/Compact/S) above it with 55 hp. Rated output across the Agrifull range ranges from 22.1 to 103 kW; here the 60 DT sits in the lower part of that range with 39.7 kW. 68 Agrifull models across 10 series are on record.

Agrifull 10 series (55 DT, 60 DT) – four-wheel-drive three-cylinder tractors from the Fiat group: 39.7 to 40.5 kW, 2,710 to 2,856 cm³ displacement, 2,010 to 2,280 kg unladen weight

The Agrifull 10 series from the Italian Fiat group comprised mid-size standard tractors with a three-cylinder engine; the 55 DT and 60 DT models carry the four-wheel drive (Doppia Trazione) of the range in the DT suffix. Like the narrow-track 200 series, the 10 series was marketed under the Fiat group's umbrella alongside Fiat's own, more broadly based standard tractors.

Read on 3 more paragraphs

The register lists here 2 versions with 39.7 to 40.5 kW from three-cylinders of 2,710 to 2,856 cm³ displacement, unladen weights from 2,010 to 2,280 kg, a length of 3,200 to 3,650 mm, a width of 1,540 to 1,740 mm, a height of 2,355 to 2,380 mm, and torque of 172 to 176 Nm at 2,300 to 2,500 rpm.

The 10 series targeted mid-size farms in Italy and elsewhere in Europe for which four-wheel drive gave a noticeable advantage in field work on sloping or heavy ground. On the used market, Agrifull 10-series models today turn up mainly in Italy and in the southern European markets formerly supplied by Fiat.

On used Agrifull 10s, condition of the front-axle drive clutch and the axle itself, tightness and shift behaviour of the gearbox, condition of injection pump and main clutch, and rust on mudguards and sheet-metal parts count; parts run through dealers specialising in Fiat/Agrifull. and the condition of the electrics. and the seat suspension.

Sources: SpecCodex register, model data: Agrifull 10er-Baureihe

Technical data

Engine

Fuel	dieselcorrect
Power	54 hp (39.7 kW)correct
Rated speed	2,300 rpmcorrect
Torque	172 Nmcorrect
Speed at max. torque	1,700 rpmcorrect
Cylinders	3correct
Displacement	2,856 cm³correct
Bore	105 mmcorrect
Stroke	110 mmcorrect
Injection pressure	176 barcorrect
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,650 mmcorrect
Width	1,740 mmcorrect
Height	2,380 mmcorrect
Wheelbase	2,145 mmcorrect
Ground clearance	330 mmcorrect
Unladen weight	2,280 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	8 V/4 Rcorrect
Front tyres	6.00-16 ASF (DT: 9.5-20 AS)correct
Rear tyres	13.6-28 AScorrect
Top speed	25 km/hcorrect

Origin and approval

Construction	frame constructioncorrect

Where this model stands

Power-to-weight ratio: 17.4 kW/t (40 kW / 2.3 t)

Power class: Universal (40–100 hp)

Stronger than 37% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Agrifull 60 DT have?

The Agrifull 60 DT delivers 54 hp.

How much does the Agrifull 60 DT weigh?

The unladen weight is 2,280 kg.

What engine does the Agrifull 60 DT have?

3 cylinders, 2,856 cm³ displacement, Diesel.

How fast does the Agrifull 60 DT go?

Top speed is 25 km/h.

What are the dimensions of the Agrifull 60 DT?

3,650 mm × 1,740 mm × 2,380 mm.

When was the Agrifull 60 DT built?

Production years: 1976–1977.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
