Agility Powertrain Systems 488LPI
Built: 2018-2021 · Series: Other models
More machines from model year 2018
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Agility Powertrain Systems – other heavy-duty road engines: CNG and LPG conversions on Ford and GM bases, 269 to 400 hp, 6.0 to 7.3-litre displacement
Agility Powertrain Systems converts Ford and GM petrol V8 and V10 base engines of 6.0, 6.8 and 7.3 litres to run on compressed natural gas (CNG) or liquefied petroleum gas (LPG); this page gathers the versions the register could not assign to a named model. The 2V and 3V codes on the Ford-based units denote two- and three-valve cylinder-head versions, and LPI on the Agility 488LPI stands for Liquid Propane Injection.
Read on 3 more paragraphs
The register lists here 8 versions with 269 to 400 hp at 4,100 to 5,100 rpm, all with sequential fuel injection. The fuel entered is natural gas (5 versions), LPG (2) and propane (1), model years run into 2018 to 2022. Maximum torque lies between 307 and 524 lb-ft (416 to 710 Nm). The range is certified for the US market.
Converted gas engines of this kind mainly supply fleet vehicles seeking lower emissions and lower fuel costs without switching to an entirely new drivetrain – for example school buses, shuttle and service vehicles, and medium-duty trucks in municipal and commercial use.
On a used converted engine, the inspection date and condition of the gas tank or LPG system, the tightness of lines and valves, the condition of spark plugs and ignition coils as typical petrol-engine wear parts, and the condition of the catalytic converter all matter. Parts for the gas system run through Agility's distribution, for the base engine through the usual Ford or GM channels.
Sources: SpecCodex register, model data: Agility Powertrain Systems (weitere Heavy-Duty-Straßenmotoren), EPA-Zertifizierungsdaten Motoren
Technical data
Engine
| Engine code | Single-Fuel LPGcorrect |
|---|---|
| Engine family | MAGIE08.0LPGcorrect |
| Engine families | MAGIE08.0LPG; LAGIE08.0LPG; KAGIE08.0LPG; JAGIE08.0LPGcorrect |
| Fuel | Liquefied Petroleum Gascorrect |
| Rated output | 252.8 kW (= 339 hp)correct |
| Rated speed | 4,100 rpmcorrect |
| Maximum torque | 495 ft·lbfcorrect |
| Speed at max. torque | 3,100 rpmcorrect |
| Displacement | 7,900 cm³correct |
| Displacement | 7.9 lcorrect |
| Operating cycle | petrol enginecorrect |
| Injection | sequential injectioncorrect |
| Aspiration | naturally aspiratedcorrect |
Origin and approval
| Version | Single-Fuel LPGcorrect |
|---|---|
| Built from | 2018correct |
| Built to | 2021correct |
| Model year from | 2018correct |
| Model year to | 2021correct |
| Sales region | USA certificationcorrect |
Other data
| Application | Vocationalcorrect |
|---|
Frequently asked questions
How much power does the Agility Powertrain Systems Agility 488LPI have?
The Agility Powertrain Systems Agility 488LPI delivers 253 kW.
What engine does the Agility Powertrain Systems Agility 488LPI have?
7,900 cm³ displacement, Liquefied Petroleum Gas.
When was the Agility Powertrain Systems Agility 488LPI built?
Production years: 2018-2021.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
6.0L 2V CNG
6.8L 2 Valve CNG
6.8L 3 Valve CNG
7.3L V8 CNG
7.3L V8 LPG
Agility 488LPI-196
PI 6.0L 2V CNG
Sources: [1]
Diesel engine in 3D section
Turn the model, look inside and click an assembly — each one is explained.
Parts for this engine (11)
Manufacturer part numbers from the official EPA documentation. No prices or availability — those come from the supplier.
| Teilenummer | Bezeichnung | Hersteller |
|---|---|---|
| 61030001 | Engine Control Module | Agility Powertrain Systems |
| 61030002 | Engine Control Module | Agility Powertrain Systems |
| FPX-0003-X-02 | Fuel pump assembly | Agility Powertrain Systems |
| FPX-003-X-02 | Fuel Pump Assem. | Agility Powertrain Systems |
| ECO-4000-X | Fuel Injector | Agility Powertrain Systems |
| FRC-0067-X-06-07 | Fuel Rail Assem. | Agility Powertrain Systems |
| 61060009 | O2 Sensor Switching | Agility Powertrain Systems |
| 61060010 | O2 Sensor Switching | Agility Powertrain Systems |
| VAX-2507-X | Pressure Regulator | Agility Powertrain Systems |
| 61060008 | Thermostat | Agility Powertrain Systems |
| 61020009 | Three-Way Catalyst | Agility Powertrain Systems |
Quelle: EPA HD Engines 2015–Present
