AGCO White 6710
Built: 1998–2001 · Series: 6010 er-Serie
More machines from model year 1998
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
AGCO White 6010 series – mid-range tractors from the US brand: 6410 to 6810, 52 to 82 kW, four- and six-cylinder engines of 3,927 to 5,889 cm³
The AGCO White 6010 series formed, in the 1990s, the mid power segment of the US brand AGCO White, whose parent group AGCO is headquartered in Duluth, Georgia; the White Farm Equipment brand was absorbed into the new corporate structure in 1991 following AGCO's takeover. The 6410 to 6810 models follow a four-digit type logic in which the last two digits mark the power step within the series – from the 6410 as the entry model to the 6810 as the most powerful version.
Read on 3 more paragraphs
The register lists here 4 versions with 52.2 to 82.4 kW, or 71 to 112 hp, from four- and six-cylinder engines of 3,927 to 5,889 cm³, unladen weights from 3,569 to 4,765 kg, torque from 319 to 498 Nm, lengths from 4,089 to 4,151 mm, a width of 1,981 mm and heights from 2,616 to 2,768 mm.
At this power class the 6010 series targeted mid-sized to larger arable farms and forage operations, competing there against Massey Ferguson, Ford/New Holland and Deutz-Fahr; like the entire AGCO White brand, the 6010 series was withdrawn from the market in the late 1990s in favour of other AGCO brands.
On a used buy, what counts is the condition of the injection pump, turbocharger and cooling system, the tightness of the hydraulics, corrosion on the chassis and wings, and the limited parts supply, since the brand has long been discontinued and spares must be sourced through independent farm-machinery dealers and aftermarket brands.
Sources: SpecCodex register, model data: AGCO White 6010er-Serie
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 96 hp (70.6 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 440 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 5,889 cm³correct |
| Bore | 102.1 mmcorrect |
| Stroke | 119.9 mmcorrect |
| Compression ratio | 17.4correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,151 mmcorrect |
|---|---|
| Width | 1,981 mmcorrect |
| Height | 2,768 mmcorrect |
| Wheelbase | 2,860 mmcorrect |
| Unladen weight | 4,717 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 32 V/32 Rcorrect |
| Forward gears | 32correct |
| Front tyres | 11.00-16 ASF (4 WD: 13.6 R 28 AS)correct |
| Rear tyres | 16.9 R 38 AS (4 WD: 18.4 R 38 AS)correct |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 160 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 15 kW/t (71 kW / 4.7 t)
Power class: Universal (40–100 hp)
Stronger than 64% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the AGCO White 6710 have?
The AGCO White 6710 delivers 96 hp.
How much does the AGCO White 6710 weigh?
The unladen weight is 4,717 kg.
What engine does the AGCO White 6710 have?
6 cylinders, 5,889 cm³ displacement, Diesel.
How fast does the AGCO White 6710 go?
Top speed is 30 km/h.
What are the dimensions of the AGCO White 6710?
4,151 mm × 1,981 mm × 2,768 mm.
When was the AGCO White 6710 built?
Production years: 1998–2001.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
