AGCO Massey Ferguson MF 6235 (A)
Built: 1999–2003 · Series: 6200er-Baureihe
More machines from model year 1999
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Massey Ferguson 6200 Series – Updated Mid-Range, 1999 to 2003, with Four- and Six-Cylinder Engines, 55.2 to 99 kW/75 to 135 hp and Operating Weight from 3,820 to 6,000 kg
The 6200 series replaced the 6100 series in 1999 and was built until 2003. According to the register, output of the recorded models ranges from 55.2 to 99 kW, using four- and six-cylinder engines with displacement from 3,990 to 5,987 cm³.
Read on 4 more paragraphs
Recorded operating weight runs from 3,820 to 6,000 kg, wheelbase from 2,485 to 2,720 mm, and top speed of the listed models is 40 km/h. Compared with the previous series, the 6200 series received a revised cab and expanded electronics.
The 6200 series targeted medium to larger arable farms and was succeeded by the 6400 series in 2003. For a used model, check the gearbox variant, as powershift and Dyna versions were offered in parallel.
With rated outputs from 55.2 to 99 kW, the 6200 series likewise fell within the ISO 730 Category II range for the rear three-point hitch, with a standard dual-speed power take-off at 540 and 1,000 revolutions per minute. Engines from the 1999 to 2003 production years still lacked exhaust gas recirculation, particulate filters or SCR technology.
Massey Ferguson remains part of the AGCO group today, so spare parts for the engine, gearbox and hydraulics of this series run through the existing AGCO parts network. Like the 6100 series, the 6200 series stayed within ISO 730 Category II and covered the same power take-off range.
Sources: SpecCodex register, model data: Massey Ferguson 6200er-Baureihe, Massey Ferguson
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 75 hp (55.2 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 289 Nmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,990 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 127 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,134 mmcorrect |
|---|---|
| Width | 1,922 mmcorrect |
| Height | 2,651 mmcorrect |
| Wheelbase | 2,485 mmcorrect |
| Ground clearance | 380 mmcorrect |
| Unladen weight | 3,820 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 16V/16R or 32V/32Rcorrect |
| Front tyres | 10.00-16 ASF (A: 13.6 R 24 AS)correct |
| Rear tyres | 16.9 R 34 AScorrect |
| Top speed | 40 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 14.5 kW/t (55 kW / 3.8 t)
Power class: Universal (40–100 hp)
Stronger than 52% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the AGCO Massey Ferguson MF 6235 (A) have?
The AGCO Massey Ferguson MF 6235 (A) delivers 75 hp.
How much does the AGCO Massey Ferguson MF 6235 (A) weigh?
The unladen weight is 3,820 kg.
What engine does the AGCO Massey Ferguson MF 6235 (A) have?
4 cylinders, 3,990 cm³ displacement, Diesel.
How fast does the AGCO Massey Ferguson MF 6235 (A) go?
Top speed is 40 km/h.
What are the dimensions of the AGCO Massey Ferguson MF 6235 (A)?
4,134 mm × 1,922 mm × 2,651 mm.
When was the AGCO Massey Ferguson MF 6235 (A) built?
Production years: 1999–2003.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
