AGCO Allis 9150

Built: 1991–1992 · Series: 9100 er- Serie

More machines from model year 1991

Source: https://storage.googleapis.com/dkrfcuuxpdfsce/do-they-still-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 9100er series from AGCO Allis includes the 9150. Production: 1991–1992. The engine delivers 152 hp (111.8 kW), has 6 cylinders, with a displacement of 6,128 cm³. The engine comes from Deutz. Rated speed is 2,400 rpm. The machine is 4,775 mm long, 2,438 mm wide and 3,099 mm high. The unladen weight is 6,133 kg. The wheelbase measures 3,048 mm. Ground clearance is 584 mm. Top speed is 30 km/h. The tank holds 348 litres. Transmission: 18 V/6 R. The engine is air-cooled. Tyres: front 11.00-16 ASF (4 WD: 14.9 R 28 AS), rear 18.4 R 38 AS. The model was built in Coldwater, OH, USA. The fuel is diesel. The bore measures 102 mm. The stroke is 125 mm. The compression ratio is 15.5:1. Construction: unit construction (no separate frame). The gearbox offers 18 forward gears. There are also 6 reverse gears. The linkage is category II/IIIN. Its predecessor was the Deutz-Allis 9150. The PTO runs at 540/1000 rpm. The 9100 er- Serie series covers 4 models. Rated output within it ranges from 137 to 196 hp; the 9150 sits in the lower part of that range with 152 hp. Its immediate neighbours are the 9130 below it with 137 hp and the 9170 above it with 174 hp. Unladen weight within it ranges from 5,579 to 7,530 kg; here the 9150 sits in the lower part of that range with 6,133 kg. 58 AGCO Allis models across 14 series are on record.

AGCO Allis 9100 series – large tractors from the US brand with Deutz six-cylinder engines: 9130 to 9190, 101 to 144 kW, 6,128 to 9,572 cm³

The AGCO Allis 9100 series formed the upper power segment of the US brand AGCO Allis, whose parent group AGCO is headquartered in Duluth, Georgia; the brand traces back to Allis-Chalmers, whose farm-machinery division passed via Deutz-Allis to the newly formed AGCO in 1990. For the 9130 to 9190 models, the register consistently lists six-cylinder engines from the German maker Deutz – a legacy of the earlier Deutz-Allis name, under which Deutz engines became a fixture of these ranges.

Read on 3 more paragraphs

The register lists here 4 versions with 100.8 to 144.2 kW, or 135 to 193 hp, from six-cylinder engines of 6,128 to 9,572 cm³, unladen weights from 5,579 to 7,530 kg, lengths from 4,775 to 5,080 mm, a width of 2,438 mm and a height of 3,099 mm.

As a large-tractor series, the 9100 line targeted farms with high draft-power needs, competing there against the large ranges from Case IH, John Deere and Massey Ferguson; like the entire brand, the 9100 series was withdrawn from the market in the late 1990s in favour of other AGCO brands.

On a used buy, for the Deutz engines what counts is the condition of the turbocharger, intercooler and injection pump, the tightness of the hydraulics under this class's high draft loads, and corrosion on the chassis and wings; parts supply for the Deutz units runs through Deutz service, while parts specific to the four-wheel-drive axle and transmission are harder to find, since the brand has been discontinued for decades.

Sources: SpecCodex register, model data: AGCO Allis 9100er-Serie

Technical data

Engine

Engine make	Deutzcorrect
Fuel	dieselcorrect
Power	152 hp (111.8 kW)correct
Rated speed	2,400 rpmcorrect
Cylinders	6correct
Displacement	6,128 cm³correct
Bore	102 mmcorrect
Stroke	125 mmcorrect
Compression ratio	15.5correct
Cooling	air-cooledcorrect

Dimensions and weights

Length	4,775 mmcorrect
Width	2,438 mmcorrect
Height	3,099 mmcorrect
Wheelbase	3,048 mmcorrect
Ground clearance	584 mmcorrect
Unladen weight	6,133 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	18 V/6 Rcorrect
Forward gears	18correct
Reverse gears	6correct
Front tyres	11.00-16 ASF (4 WD: 14.9 R 28 AS)correct
Rear tyres	18.4 R 38 AScorrect
Top speed	30 km/hcorrect

Working data

Fuel tank capacity	348 lcorrect

Origin and approval

Plant	Coldwater, OH, USAcorrect
Construction	unit construction (no separate frame)correct

Other data

Linkage category	Cat II/IIINcorrect
PTO speed	540/1000 rpmcorrect
Predecessor	Deutz-Allis 9150correct

Where this model stands

Power-to-weight ratio: 18.2 kW/t (112 kW / 6.1 t)

Power class: Large (100–180 hp)

Stronger than 84% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the AGCO Allis 9150 have?

The AGCO Allis 9150 delivers 152 hp.

How much does the AGCO Allis 9150 weigh?

The unladen weight is 6,133 kg.

What engine does the AGCO Allis 9150 have?

6 cylinders, 6,128 cm³ displacement, Diesel.

How fast does the AGCO Allis 9150 go?

Top speed is 30 km/h.

What are the dimensions of the AGCO Allis 9150?

4,775 mm × 2,438 mm × 3,099 mm.

When was the AGCO Allis 9150 built?

Production years: 1991–1992.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
