Zoda MEPS-280M-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Zoda – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, YE2 standard range and MEPS scheme, frame sizes 132 to 280, 7.5 to 132 kW, 2- to 4-pole
This page gathers the Zoda three-phase motors the Australian energy-efficiency register (MEPS) could not assign to a named range. Zoda is a Chinese maker of three-phase motors for the Australian and South-East Asian markets. The designations in the register follow two schemes: a "MEPS" prefix with frame size and pole count, such as MEPS-160L-4, and the YE2 range, a standard series widespread in China for three-phase motors with raised efficiency, in part in the open IP23 version YE2(IP23). One model, VSD280, is recognisably intended for operation on a variable-speed drive.
Read on 3 more paragraphs
The register lists here 23 versions with 7.5 to 132 kW, two- to four-pole, full-load efficiencies from 89.43 to 95.04% and at 75% load from 89.23 to 94.48%. Frame sizes run from 132 to 280, supply voltage from 400 to 415 V, protection is mostly IP55. Manufacturing is exclusively in China, testing followed the 2019 GEMS determination with test methods A, 2-1-1B and B; none of the 15 classified motors reaches a High Efficiency Level.
Zoda positions itself among the numerous Chinese suppliers of IEC standard motors that gain access to the Australian industrial-drive market through MEPS registration; the range covers mid-range power classes for pumps, fans and conveyors, with the VSD280 also a version for variable-speed applications.
When buying used, bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and protection rating matter; on the VSD280 version, inverter suitability is also worth checking. Spares run through the distribution for Chinese standard motors.
Sources: SpecCodex register, model data: Zoda (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 90 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 280 M (foot)correct |
| Mounting (IEC 60034-7) | B35correct |
| Efficiency at full load | 94.29 %correct |
| Efficiency at 75 % load | 94.26 %correct |
| Efficiency at half load | 93.52 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Zoda MEPS-280M-2 have?
The Zoda MEPS-280M-2 delivers 90 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
