Zhejiang Xingyu 178F
Built: 2011 · Series: Other models
More machines from model year 2011
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Zhejiang Xingyu – other nonroad diesel engines: the collective page of EPA-certified single-cylinder small diesel engines outside the named ranges, 4 to 6 kW, 3,600 rpm, model years 2011 to 2012, Tier 4 Final
Zhejiang Xingyu, headquartered in Zhejiang province, builds small air-cooled diesel engines for agricultural equipment and mobile drives. The versions listed here, 178F, 186F and 186FA, carry the size-designation codes common across China's small-engine industry, in which the digit sequence denotes cylinder bore and build size. This page gathers the models outside the named ranges.
Read on 3 more paragraphs
The register lists here 3 versions with 4 to 6 kW rated output, all at 3,600 rpm, all single-cylinder with 78 to 86 mm bore and 62 to 72 mm stroke. Maximum torque ranges from 10.6 to 16.15 Nm, model years from 2011 to 2012; all three versions run direct injection at the Tier 4 (Final or Phase-in) emission stage and the under 8 kW power category.
The three versions form a closely staggered power series for portable generator sets, water pumps and simple agricultural machinery; the small differences in bore and stroke between the models allow fine steps in rated output within the same base engine.
On a used purchase, the oil level counts, along with the cooling fins on the air-cooled design, the condition of the injector and the tightness of the cylinder head gasket; on the older model years from 2011, it is also worth checking the fuel lines and starter motor.
Sources: SpecCodex register, model data: Zhejiang Xingyu (weitere Nonroad-Dieselmotoren)
Technical data
Engine
| Engine family | CYKXL0.42AAA; BYKXL0.42AAAcorrect |
|---|---|
| Engine families | CYKXL0.42AAA; BYKXL0.42AAAcorrect |
| Fuel | 300-500 ppm Low Sulfur Dieselcorrect |
| Rated output | 4 kWcorrect |
| Power band | kW<8correct |
| Rated speed | 3,600 rpmcorrect |
| Maximum torque | 10.6 N·mcorrect |
| Speed at max. torque | 3,600 rpmcorrect |
| Cylinders | 1correct |
| Cylinder layout | in linecorrect |
| Bore | 78 mmcorrect |
| Stroke | 62 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | naturally aspiratedcorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Built from | 2011correct |
|---|---|
| Built to | 2012correct |
| Model year from | 2011correct |
| Model year to | 2012correct |
Frequently asked questions
How much power does the Zhejiang Xingyu 178F have?
The Zhejiang Xingyu 178F delivers 4 kW.
When was the Zhejiang Xingyu 178F built?
Production years: 2011.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
