Zetor Z-15

Built: 1947–1948 · Series: Other models

More machines from model year 1947

Source: zetor.com

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Zetor Z-15 is a machine built by Zetor. Production: 1947–1948. The engine delivers 15 hp (11 kW), has 1 cylinder, with a displacement of 1,583 cm³. Rated speed is 1,500 rpm. The machine is 2,700 mm long, 1,570 mm wide and 1,550 mm high. The unladen weight is 1,399 kg. The wheelbase measures 1,560 mm. Ground clearance is 320 mm. Top speed is 20 km/h. Transmission: 5 V/1 R. The engine is water-cooled. Tyres: front 5.50-16 ASF, rear 9.00-24 AS. The fuel is diesel. The bore measures 120 mm. The stroke is 140 mm. The compression ratio is 18:1. Construction: unit construction (no separate frame). Around 2.215 units were built. Rated output across the Zetor range ranges from 15 to 160 hp; the Z-15 sits at the bottom of that range with 15 hp. Its immediate neighbours are the 2011 above it with 22 hp. Rated output across the Zetor range ranges from 11 to 117.7 kW; here the Z-15 sits at the bottom of that range with 11 kW. 371 Zetor models across 27 series are on record.

Zetor — where the name comes from and how the ranges connect, models from 11 to 120 kW, engines including Caterpillar, Perkins, Zetor and Deutz

The brand name is a compound: the "Z" of the Brno arms factory Zbrojovka and the ending "-tor". It was there, in March 1946, that the first three Z 25 tractors left the line — an eightieth anniversary in 2026.

Read on 4 more paragraphs

Order among the many Zetor types came in the 1960s with the unified UR I and UR II ranges. They brought more modern engineering and, above all, shared central components — the reason parts can be swapped across model boundaries. In the late 1960s the UR II joined the programme, designed for stronger machines and more demanding work.

Those lines still run today. The UR II range was revised and reached the market in 1998 as the Zetor Forterra. Around the turn of the millennium came the Proxima and Forterra ranges together with the modernised Major and Crystal — the generation carrying the brand through its recent history.

Anyone assessing an older model should therefore identify the base range first. A tractor from the UR II family is technically related to the Forterra, even with decades between them. That kinship decides how readily parts can be found — with a brand spanning eighty years of models, that is the most practical question of all.

Across the whole power range gathered here, 11 to 120 kW, the ISO 730 three-point linkage spans Category 0 on the smallest post-war models to Category II on the stronger series; the 540 rpm PTO speed remained, across the decades, the unchanged common denominator of every Zetor generation.

Sources: SpecCodex register, model data: Zetor (weitere Modelle), Zetor

Technical data

Engine

Fueldieselcorrect
Power15 hp (11 kW)correct
Rated speed1,500 rpmcorrect
Cylinders1correct
Displacement1,583 cm³correct
Bore120 mmcorrect
Stroke140 mmcorrect
Compression ratio18correct
Coolingwater-cooledcorrect

Dimensions and weights

Length2,700 mmcorrect
Width1,570 mmcorrect
Height1,550 mmcorrect
Wheelbase1,560 mmcorrect
Ground clearance320 mmcorrect
Unladen weight1,399 kgcorrect

Drivetrain and chassis

Driverear-wheel drivecorrect
Gearbox5 V/1 Rcorrect
Front tyres5.50-16 ASFcorrect
Rear tyres9.00-24 AScorrect
Top speed20 km/hcorrect

Origin and approval

Constructionunit construction (no separate frame)correct
Units built2,215correct

Where this model stands

Power-to-weight ratio: 7.9 kW/t (11 kW / 1.4 t)

Power class: Compact (< 40 hp)

Stronger than 3% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Zetor Z-15 have?

The Zetor Z-15 delivers 15 hp.

How much does the Zetor Z-15 weigh?

The unladen weight is 1,399 kg.

What engine does the Zetor Z-15 have?

1 cylinders, 1,583 cm³ displacement, Diesel.

How fast does the Zetor Z-15 go?

Top speed is 20 km/h.

What are the dimensions of the Zetor Z-15?

2,700 mm × 1,570 mm × 1,550 mm.

When was the Zetor Z-15 built?

Production years: 1947–1948.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
  • Shift the gearbox cold and warm — jumps only show up at temperature.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
