KhTZ XTZ-16131-03
Series: XTZ-16131
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Xtz XTZ-16131-03 – heavy six-cylinder tractor: 5,700 cc displacement, 180 hp and 132 kW at 2,300 rpm, 2,470 mm wide, 500 mm ground clearance
The XTZ-16131-03 comes from the Kharkiv Tractor Plant XTZ in Ukraine and belongs to the 16000 series of heavy wheeled tractors. Nothing certain can be added about further details of the company's history from the recorded values.
Read on 3 more paragraphs
The water-cooled six-cylinder diesel engine has a displacement of 5,700 cc and produces 180 hp, or 132 kW, at 2,300 rpm. At 6,640 mm long, 2,470 mm wide, 3,380 mm high, with a 2,860 mm wheelbase and 500 mm ground clearance, the XTZ-16131-03 is a large, heavy field tractor with comparatively generous ground clearance.
180 hp from only 5,700 cc at 2,300 rpm points to a turbocharged, short-stroke engine that draws more power from less displacement at higher revs than a classic naturally aspirated unit. The 500 mm ground clearance is unusually tall for this tractor class and allows work over uneven ground or ground covered in crop residue.
When buying a used turbocharged six-cylinder of this kind, the condition of the turbocharger, the tightness of the charge-air system and regular oil changes matter most, as highly loaded diesel engines respond more sensitively to neglected maintenance. It is also worth checking the wide front axle and the braking system given the high overall weight, along with the seals of the intercooler for signs of leaking boost pressure.
Sources: SpecCodex-Register: Kennwerte des Modells Xtz XTZ-16131-03
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 180 hp (132 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 5,700 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 6,640 mmcorrect |
|---|---|
| Width | 2,470 mmcorrect |
| Height | 3,380 mmcorrect |
| Wheelbase | 2,860 mmcorrect |
| Ground clearance | 500 mmcorrect |
Frequently asked questions
How much power does the KhTZ XTZ-16131-03 have?
The KhTZ XTZ-16131-03 delivers 180 hp.
What engine does the KhTZ XTZ-16131-03 have?
6 cylinders, 5,700 cm³ displacement, Diesel.
What are the dimensions of the KhTZ XTZ-16131-03?
6,640 mm × 2,470 mm × 3,380 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
