Wullhorst TGS 18.360
Built: 2014 · Series: Other models
More machines from model year 2014
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Wullhorst TGS 18.360 (2014): three-axle chassis with a 10,518 cm³ six-cylinder engine, 19,000 kg gross vehicle weight, 5,500 mm wheelbase and a 90 km/h top speed
The TGS 18.360 type designation follows the naming pattern common on heavy trucks, in which the first number states the weight class in tonnes and the second the engine output in metric horsepower. The 2014 entry describes a chassis of this weight and power class, fitted with a six-cylinder engine.
Read on 3 more paragraphs
The engine displaces 10,518 cm³ across six cylinders. With a gross vehicle weight of 19,000 kg and a kerb weight of 11,740 kg, around 7,260 kg remains for payload and body. A length of 10,090 mm, a wheelbase of 5,500 mm and six wheels point to a typical three-axle layout, with a design top speed of 90 km/h.
At a gross weight of 19,000 kg, the vehicle belongs to EU class N3, the heavy trucks above 12 tonnes, for which the EU sets a top speed of 90 km/h – exactly the figure this vehicle is limited to by design. A wheelbase of 5,500 mm is a common figure for a three-axle chassis carrying a tipper, mixer or construction body, allowing short overhangs and good manoeuvrability on tight sites.
When buying a three-axle chassis of this weight class, the key points are the condition of the air or leaf suspension on the rear axle, wear in the steering and braking systems, and corrosion on the frame rails and axle mounts. With an engine displacing over 10 litres, it is also worth checking the turbocharger, injection pump and mileage since the last engine overhaul.
Sources: SpecCodex-Register: Kennwerte des Modells Wullhorst TGS 18.360
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 10,518 cm³correct |
Dimensions and weights
| Length | 10,090 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Wheelbase | 5,500 mmcorrect |
| Unladen weight | 11,740 kgcorrect |
| Gross vehicle weight | 19,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 90 km/hcorrect |
Frequently asked questions
How much does the Wullhorst TGS 18.360 weigh?
The unladen weight is 11,740 kg.
What is the gross vehicle weight of the Wullhorst TGS 18.360?
19,000 kg.
What engine does the Wullhorst TGS 18.360 have?
6 cylinders, 10,518 cm³ displacement.
How fast does the Wullhorst TGS 18.360 go?
Top speed is 90 km/h.
What are the dimensions of the Wullhorst TGS 18.360?
10,090 mm × 2,600 mm.
When was the Wullhorst TGS 18.360 built?
Production years: 2014.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 12 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Sources: RDW — Dutch national vehicle register (retrieved August 2026) · How we check the data
