Wolfenbütteler Traktoren GmbH 22 PS
Built: 1/1949–1950 · Series: WoTrak
More machines from model year 1949
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Wolfenbütteler Traktoren WoTrak 22 hp – German post-war tractor built 1949 to 1950: two-cylinder diesel of 2,198 cc, 22 hp at 1,500 rpm, 1,700 kg weight, circulating water cooling
Wolfenbütteler Traktoren GmbH already carries the town of Wolfenbüttel in Lower Saxony in its name; the WoTrak 22 hp was built in the first post-war year of 1949 and continued until 1950, a time when many smaller German works produced their own tractors to help rebuild agriculture.
Read on 3 more paragraphs
The two-cylinder diesel engine of 2,198 cc is cooled by water circulation and produces 22 hp, or 16.2 kW, at 1,500 rpm. At 1,700 kg, 2,300 mm long, with a 1,630 mm wheelbase and 1,520 mm width, the WoTrak reaches a design top speed of 18.5 km/h.
Tractors of this power class from the immediate post-war years were intended as versatile workhorses for medium-sized farms, with simple circulating water cooling rather than more elaborate thermosiphon or evaporative technology. The two-cylinder layout was a compromise between smooth running and simple, robust engineering, as offered by many small makers of those years.
When buying such a rare post-war tractor, the condition of the cylinder head and cooling circuit is decisive, as corrosion in old circulating water systems is common. Because such small-series makers built only limited numbers, original spare parts are hard to find, so the condition and completeness of the machine weigh more heavily on its value than with any mass-produced model of the same era.
Sources: SpecCodex-Register: Kennwerte des Modells Wolfenbütteler Traktoren WoTrak 22 PS
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 22 hp (16.2 kW)correct |
| Rated speed | 1,500 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 2,198 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,300 mmcorrect |
|---|---|
| Width | 1,520 mmcorrect |
| Height | 1,273 mmcorrect |
| Wheelbase | 1,630 mmcorrect |
| Ground clearance | 330 mmcorrect |
| Unladen weight | 1,700 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4V+1Rcorrect |
| Front tyres | 5.00-16correct |
| Rear tyres | 9.00-24correct |
| Top speed | 18.5 km/hcorrect |
Origin and approval
| Construction | frameless unit constructioncorrect |
|---|---|
| Units built | 40correct |
Where this model stands
Power-to-weight ratio: 9.5 kW/t (16 kW / 1.7 t)
Power class: Compact (< 40 hp)
Stronger than 9% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Wolfenbütteler Traktoren GmbH 22 PS have?
The Wolfenbütteler Traktoren GmbH 22 PS delivers 22 hp.
How much does the Wolfenbütteler Traktoren GmbH 22 PS weigh?
The unladen weight is 1,700 kg.
What engine does the Wolfenbütteler Traktoren GmbH 22 PS have?
2 cylinders, 2,198 cm³ displacement, Diesel.
How fast does the Wolfenbütteler Traktoren GmbH 22 PS go?
Top speed is 18.5 km/h.
What are the dimensions of the Wolfenbütteler Traktoren GmbH 22 PS?
2,300 mm × 1,520 mm × 1,273 mm.
When was the Wolfenbütteler Traktoren GmbH 22 PS built?
Production years: 1/1949–1950.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
