Witteveen DR 3500
Built: 1989-2014 · Series: DR
More machines from model year 1989
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Witteveen DR – light Dutch long trailers around 3.5 t: the DR 3500 range, unladen weight from 890 kg, lengths over 10.6 m for boat and machinery transport
Witteveen is a Dutch manufacturer of light, long tandem-axle trailers, widely used for transporting boats and machinery. The DR range mainly bundles versions in the roughly 3,500-kilogram gross-weight class – the DR 3500, DR 3502, DR 3560 and the S and VAR. C1 variants – whose type number directly matches the gross weight in kilograms. The very low unladen weight at a great length is typical of open, light frame constructions without an enclosed body.
Read on 3 more paragraphs
The register lists 8 versions with unladen weights from 890 to 1,980 kg at a gross weight of 3,500 to 5,400 kg. Lengths range from 10,610 to 11,050 mm, widths from 2,000 to 2,350 mm.
At lengths of over 10 metres and an unladen weight at times under a tonne, the DR trailers suit the transport of long but comparatively light loads such as boats, pipes or construction machinery with a low unladen weight. In the Netherlands, with its dense network of waterways and inland shipping, this segment of light, long tandem-axle trailers is firmly established.
When buying used, the key checks are corrosion on the open frame, the condition of the axles, suspension and braking system, and the operation of the overrun brake. On boat trailers, the keel rollers, light board and corrosion from saltwater contact should also be checked; spare parts run through Dutch specialist trailer dealers.
Sources: SpecCodex register, model data: Witteveen DR, Zulassungsdaten RDW (Niederlande)
Technical data
Dimensions and weights
| Length | 10,610 mmcorrect |
|---|---|
| Width | 2,250 mmcorrect |
| Wheelbase | 6,450 mmcorrect |
| Unladen weight | 1,190 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Witteveen DR 3500 weigh?
The unladen weight is 1,190 kg.
What is the gross vehicle weight of the Witteveen DR 3500?
3,500 kg.
Up to what speed is the Witteveen DR 3500 approved?
Approved up to 100 km/h.
What are the dimensions of the Witteveen DR 3500?
10,610 mm × 2,250 mm.
When was the Witteveen DR 3500 built?
Production years: 1989-2014.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
