Winton Semi Trailer N.A.
Built: 2025 · Series: Other models
More machines from model year 2025
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Winton Semi Trailer – other models: the collective page of three-axle semi-trailers outside the named ranges, with and without self-supporting body, 4.4 to 6.5 t unladen weight, 45 t gross weight, 9.16 to 13.22 m length
This page gathers the Winton Semi Trailer trailers the register could not assign to a named range. The model names describe the construction directly: a three-axle semi-trailer and a version with a self-supporting body, in which the tank or box itself contributes to the vehicle's rigidity instead of resting solely on a load-bearing frame.
Read on 3 more paragraphs
The register lists here 3 versions with unladen weights from 4,400 to 6,500 kg, a gross weight of 45,000 kg, lengths from 9,160 to 13,220 mm and a width of 2,550 mm.
With a uniform gross weight of 45 tonnes, the whole collective page sits within class O4, the range of semi-trailers for heavy transport; the unladen-weight span of roughly 4.4 to 6.5 tonnes at the same gross weight shows the difference between the lighter standard three-axle version and the sturdier but heavier self-supporting-body construction.
On a used semi-trailer of this class, the air-brake system with ABS and EBS matters, along with the kingpin and fifth-wheel plate for wear, the three axles and their brake drums or discs, the frame or, on self-supporting bodies, the outer skin for cracks and corrosion, and the landing legs and tyres for even wear. At such a high gross weight it is also worth tracing the inspection history and any previous repairs to the frame and suspension.
Sources: SpecCodex register, model data: Winton Semi Trailer (weitere Modelle)
Technical data
Dimensions and weights
| Length | 13,220 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 7,520 mmcorrect |
| Unladen weight | 6,500 kgcorrect |
| Gross vehicle weight | 45,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Winton Semi Trailer N.A. weigh?
The unladen weight is 6,500 kg.
What is the gross vehicle weight of the Winton Semi Trailer N.A.?
45,000 kg.
Up to what speed is the Winton Semi Trailer N.A. approved?
Approved up to 100 km/h.
What are the dimensions of the Winton Semi Trailer N.A.?
13,220 mm × 2,550 mm.
When was the Winton Semi Trailer N.A. built?
Production years: 2025.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
