Winsun Power 188FB
Built: 2012 · Series: Other models
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Winsun Power – other nonroad diesel engines: the EPA register of the 188FB single-cylinder and R2V840 V-twin, 2012 model year, Tier 4 from below 8 to below 19 kW
The US EPA classifies small diesel engines for mobile equipment by power category; Winsun Power offers the 188FB, a horizontal single-cylinder, and the R2V840, a V-twin, neither of which the register could assign to a named range. The single-cylinder falls into the EPA category below 8 kW, the twin-cylinder into the 8 to below 19 kW category, both in the Tier 4 (Final or Phase-in) emission stage.
Read on 3 more paragraphs
The register lists here 2 versions from the 2012 model year, with 7 to 12 kW rated output at a constant 3,600 rpm and 86 to 88 mm bore with 72 to 75 mm stroke – short-stroke in design. Maximum torque ranges from 18.4 to 33.3 Nm, again at 3,600 rpm; both versions run direct injection and low-sulphur diesel with 300 to 500 ppm sulphur content.
The single-cylinder suits portable generator sets and water pumps, while the V-twin suits larger units where two cylinders give smoother running; both layouts belong to the standard repertoire of Chinese small-diesel manufacturers exporting to the US market.
When buying used, on the single-cylinder what counts is the tightness of the injection pump, and on the V-twin additionally the even running of both cylinders and the tightness of the cylinder-head gaskets; corrosion on the fuel tank and frame is common on generator sets run outdoors. Spare parts for these engine formats are available through the general trade for Chinese small diesel engines.
Sources: SpecCodex register, model data: Winsun Power (weitere Nonroad-Dieselmotoren)
Technical data
Engine
| Engine family | CNWSL.456AAAcorrect |
|---|---|
| Engine families | CNWSL.456AAAcorrect |
| Fuel | 300-500 ppm Low Sulfur Dieselcorrect |
| Rated output | 7 kWcorrect |
| Power band | kW<8correct |
| Rated speed | 3,600 rpmcorrect |
| Maximum torque | 18.4 N·mcorrect |
| Speed at max. torque | 3,600 rpmcorrect |
| Cylinders | 1correct |
| Cylinder layout | in linecorrect |
| Bore | 88 mmcorrect |
| Stroke | 75 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | naturally aspiratedcorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Built from | 2012correct |
|---|---|
| Built to | 2012correct |
| Model year from | 2012correct |
| Model year to | 2012correct |
Frequently asked questions
How much power does the Winsun Power 188FB have?
The Winsun Power 188FB delivers 7 kW.
When was the Winsun Power 188FB built?
Production years: 2012.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
