WAT Q3H112M2D
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
WAT – other models: the collective page for two-pole three-phase motors outside the named series, frame sizes 80 to 160, 0.75 to 22 kW, flange and vertical mounting only, made in Turkey
This page gathers three-phase motors from the Turkish manufacturer WAT that the register does not assign to a named series. The type plates Q3H112M2D through Q3H160L2D combine a series code with the IEC frame size and the pole count 2; every model on this collective page is built consistently as two-pole, and so designed for high speeds around 2,900 revolutions per minute.
Read on 3 more paragraphs
The register lists 11 versions with 0.75 to 22 kW rated output, two-pole throughout, at supply voltages of 400 V or 230/400 V. Full-load efficiency ranges from 80.7 to 92.7%, and at 75% load from 79.7 to 92.7%. Frame sizes span 80 to 160, and the protection class is IP55 throughout.
The exclusive use of the V1 and V18 mounting codes shows that this range is not designed as a classic foot-mounted motor but consistently for flange or vertical mounting, as is common for pumps or compressors flanged directly to the motor. The consistent restriction to two poles underlines a focus on fast-running applications.
For a replacement, these motors call above all for the mounting code, V1 or V18, to match the existing mounting interface exactly, since conversion to foot mounting is not provided for in this range. Winding condition and bearing noise should be checked especially carefully given the high operating speeds of the two-pole motors.
Sources: Kennwerte der Modelle WAT (weitere Modelle), GEMS/MEPS (Australien, Neuseeland)
Technical data
Engine
| Rated output | 5.5 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 112 M (foot)correct |
| Mounting (IEC 60034-7) | V1correct |
| Efficiency at full load | 89.3 %correct |
| Efficiency at 75 % load | 89 %correct |
| Efficiency at half load | 87.1 %correct |
Origin and approval
| Country of manufacture | Turkeycorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the WAT Q3H112M2D have?
The WAT Q3H112M2D delivers 5.5 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
