Volkswagen DELIVERY VAN

Built: 1956-1966 · Series: Vans up to 3.5 t (Class N1)

More machines from model year 1956

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The DELIVERY VAN from Volkswagen is part of the Vans up to 3.5 t (Class N1) series. Production: 1956-1966. The engine has 4 cylinders, with a displacement of 1,500 cm³. The vehicle is 1,730 mm wide. The unladen weight is 1,050 kg. The wheelbase measures 2,410 mm. The gross vehicle weight is 2,070 kg. The vehicle runs on 4 wheels. The fuel is Diesel | Gas | Petrol. The Vans up to 3.5 t (Class N1) series covers 2252 models. Unladen weight within it ranges from 660 to 3,370 kg; the DELIVERY VAN sits at the bottom of that range with 1,050 kg. Its immediate neighbours are the 26 PICK UP below it with 1,045 kg and the TRANSPORTER T2 PICK UP above it with 1,051 kg. Gross vehicle weight within it ranges from 1,140 to 3,500 kg; here the DELIVERY VAN sits in the lower part of that range with 2,070 kg. 4967 Volkswagen models across 73 series are on record.

Volkswagen Transporter — Crafter was a Mercedes Sprinter in disguise until 2016

Volkswagen groups several very different ranges under the Transporter name, all under 3.5 tonnes: the compact Caddy, the actual Transporter across the T5, T6, T6.1 and the newest generation delivered since February 2025, and the larger Crafter. The key technical distinction concerns the Crafter: the first generation, built from 2006 to November 2016, was essentially a Mercedes-Benz Sprinter wearing a VW badge, built jointly with Mercedes at the Düsseldorf and Ludwigsfelde plants. The second generation, on sale from 2017, is an independent Volkswagen design, built at a newly constructed factory in Września, Poland. Telling the ranges apart therefore requires checking both size and build year.

Read on 3 more paragraphs

The Caddy is the most compact range, with a gross vehicle weight of roughly 2,150 to 2,450 kilograms depending on body style — Caddy, Caddy Kombi or Caddy Maxi. It shares its floor platform with the Golf and is mostly used for smaller deliveries and as a tradesperson's vehicle. The classic Transporter, in its T5, T6 and T6.1 generations, covered the mid-size class for decades and was built in Hanover. Its direct successor, delivered since February 2025, is technically no longer an independent Volkswagen design — it is built on the Ford Transit Custom platform, alongside that model, at the Ford Otosan plant in Turkey, with Volkswagen contributing mainly the interior and body detailing.

The Crafter is the largest range, offered in the Crafter 30 (around 3 tonnes), Crafter 35 (3.5 tonnes) and Crafter 50 (5 tonnes) weight classes. The 5-tonne version therefore exceeds the upper limit of the N1 category and is formally classed as N2. Orders for the second-generation Crafter opened in November 2016, with the first deliveries following in March 2017. Before that, the Crafter differed from the Sprinter externally in little more than the front end, tail lights and engines fitted.

When buying a used Crafter, generation is the decisive difference: vehicles up to model year 2016 are technically equivalent to the second-generation Sprinter, so some spare and wear parts can be swapped between the two brands. The Crafter from 2017 onward has its own design and its own parts structure at Volkswagen, incompatible with the older Sprinter. It is worth checking the exact production date and chassis number before buying, not just the exterior look. A similar point now applies to the newest Transporter: buying one means technically buying a Ford-based vehicle, even though sales, servicing and warranty run through Volkswagen.

Sources: Wikipedia: VW Crafter (Generationen, Werke, Zeiträume) (Wikipedia), MeinAuto.de: VW Caddy technische Daten, amz.de: neuer VW Transporter basiert auf Ford Transit Custom, Wikipedia: Volkswagen Transporter (2024), Produktion Ford Otosan Türkei, Marktstart Februar 2025 (Wikipedia)

Technical data

Engine

FuelDiesel | Gas | Petrolcorrect
Cylinders4correct
Displacement1,500 cm³correct

Dimensions and weights

Width1,730 mmcorrect
Wheelbase2,410 mmcorrect
Unladen weight1,050 kgcorrect
Gross vehicle weight2,070 kgcorrect

Drivetrain and chassis

Wheels4correct

Origin and approval

VersionDELIVERY VANcorrect
Number of versions1correct
Built from1953correct
Built to1999correct
First registered from1,964correct
First registered to1,999correct

Frequently asked questions

How much does the Volkswagen DELIVERY VAN weigh?

The unladen weight is 1,050 kg.

What is the gross vehicle weight of the Volkswagen DELIVERY VAN?

2,070 kg.

What engine does the Volkswagen DELIVERY VAN have?

4 cylinders, 1,500 cm³ displacement, Diesel | Gas | Petrol.

When was the Volkswagen DELIVERY VAN built?

Production years: 1956-1966.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
