Vogele Super 1100-2
Series: Vogele Asphalt Paver
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Vögele pavers Super 800 to Super 2500 and Vision 5100 to 5200 – the world market leader from Ludwigshafen: Super as range, the number as size class, -2 as generation, 03 for wheeled pavers, Vision as North American range, Deutz, Perkins and Cummins engines, 45 to 273 kW
Vögele of Ludwigshafen on the Rhine is the world's largest maker of road pavers – a machine works since 1836, in road building since the 1920s, part of the Wirtgen Group since 1996 and with it at John Deere since 2017. The type logic: Super marks the paver range, the number the size class – Super 800 the small paver for footpaths, Super 1100 and 1300 the compact class, Super 1600 and 1800 the universal class, Super 1900, 2100 and 2500 the big motorway pavers with paving widths up to 16 metres – -2 the second generation of the 2000s, the final digits 03 (1103, 1303, 1603, 1803) the wheeled pavers as against the tracked pavers with final digits 00; Vision 5100 and 5200 are the pavers developed for North America in the American layout with the auger at the front. The engines come from Deutz (TCD 2011) in the small, Perkins (1104D, 1106D) in the medium and Cummins (QSB 6.7) in the big and American models, at 1,800 to 2,300 rpm.
Read on 3 more paragraphs
The register lists 16 versions with 45 to 273 kW from four- and six-cylinders.
Vögele holds more than half of the European paver market; the Super 1800 and 1900 are the standard machines of German road building, the high-compaction screeds (TP, TV) and the Niveltronic grade control are regarded as the reference of the class.
On used pavers, operating hours, the condition of the screed (wear plates, heating, tampers and pressure bars), conveyors, augers and scrapers, tracked or wheeled undercarriage, hydraulics and grade control and parts supply through the Wirtgen Group, which is dense worldwide, count.
Sources: Kennwerte der Modelle Vögele Straßenfertiger, Joseph Vögele AG (Wirtgen Group, Hersteller, Ludwigshafen)
Technical data
Engine
| Engine model | TCD2011L04wcorrect |
|---|---|
| Power | 78.9 hp (58 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
Working data
| Fuel tank capacity | 120.4 lcorrect |
|---|
Other data
| System voltage | 24 Vcorrect |
|---|
Frequently asked questions
How much power does the Vogele Super 1100-2 have?
The Vogele Super 1100-2 delivers 78.9 hp.
What engine does the Vogele Super 1100-2 have?
4 cylinders.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 7 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
