Versatile 520
Built: 2018-2018 · Series: Other models
Built in 2018, the Versatile 520 is a tractor from Versatile. It is powered by a six-cylinder engine producing 387.8 kW. Rated power is reached at 1,800 rpm.
Gearbox: TA22 full power shift; drive type: 4WD (articulated).
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 75 to 451 kW; with 388 kW, the 520 sits at the top. Directly alongside are the 485 with 362 kW below and the 535 with 399 kW above.
Technical data
Engine
| Engine make | Cumminscorrect |
|---|---|
| Engine model | QSX15correct |
| Fuel | dieselcorrect |
| Power | 520 hp (387.8 kW)correct |
| Rated speed | 1,800 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 14.9 lcorrect |
| Bore | 137 mmcorrect |
| Stroke | 169 mmcorrect |
| Turbocharger | yescorrect |
| Cooling | liquid-cooledcorrect |
Dimensions and weights
| Wheelbase | 391 cmcorrect |
|---|
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | TA22 full power shiftcorrect |
| Gearbox make | Caterpillarcorrect |
| Forward gears | 16correct |
| Reverse gears | 4correct |
Working data
| PTO speed | 1,000correct |
|---|---|
| Linkage category | Cat. IVcorrect |
Origin and approval
| Plant | Winnipeg, Manitoba, Canadacorrect |
|---|---|
| Cab | Enclosed, air-conditionedcorrect |
Frequently asked questions
How much power does the Versatile 520 have?
The Versatile 520 delivers 520 hp.
What engine does the Versatile 520 have?
6 cylinders, Diesel.
When was the Versatile 520 built?
Production years: 2018.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
