Versatile 1156
Built: 1986-1987 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Versatile 1156 rolled off the line in 1986-1987 as a tractor. The six-cylinder engine produces 350 kW. Rated speed is 2,100 rpm.
It runs on diesel; the engine is water-cooled. It replaced the Versatile 1150 and was in turn replaced by the Ford Versatile 1156. Within the range, rated power spans from 75 to 451 kW; with 350 kW, the 1156 sits in the upper third. Directly alongside are the 460 with 343 kW below and the 485 with 362 kW above.
Technical data
Engine
| Engine make | Cumminscorrect |
|---|---|
| Engine model | KTA-1150Ccorrect |
| Fuel | dieselcorrect |
| Power | 470 hp (350 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 1150 cu incorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 140 in (3 556 mm)correct |
|---|---|
| Turning circle | 15.16 ftcorrect |
| Unladen weight | 25,500 lbs (11566,6 kg)correct |
Drivetrain and chassis
| Drive | four-wheel driveWDcorrect |
|---|---|
| Forward gears | 8correct |
| Reverse gears | 4correct |
Working data
| Fuel tank capacity | 400 galcorrect |
|---|---|
| PTO speed | 1,000correct |
Origin and approval
| Plant | Winnipeg, Manitoba, Canadacorrect |
|---|---|
| Predecessor | Versatile 1150correct |
| Successor | Ford Versatile 1156correct |
Frequently asked questions
How much power does the Versatile 1156 have?
The Versatile 1156 delivers 470 hp.
What engine does the Versatile 1156 have?
6 cylinders, Diesel.
When was the Versatile 1156 built?
Production years: 1986-1987.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
