UpRight AB46E 2WD
Series: UpRight Boom Lift
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
UpRight Boom Lift: articulating and telescopic boom lifts from AB38W to SB85J with Deutz and Kubota engines, 22 to 60.4 kW, 2,570 to 19,119 kg weight
UpRight was a US manufacturer of mobile access platforms whose range is now continued under the Snorkel brand. This page gathers the self-propelled articulating and telescopic boom lifts: AB denotes the articulating boom, SB the straight telescopic boom, and MB the mast boom, while the suffixes 2WD, 4WD and RT mark drive and terrain capability. The lifts are powered by air-cooled Deutz engines of the F3L-2011 and F4L-2011 range and by Kubota diesels of the V1505 and V1505T type.
Read on 3 more paragraphs
The register lists here 13 versions with 22 to 60.4 kW, weights from 2,570 to 19,119 kg, lengths from 1,075 to 8,900 mm and widths from 810 to 2,603 mm.
Boom lifts of this kind are used in construction, industrial maintenance and facade work for working heights scissor lifts cannot reach; UpRight ranked alongside Genie and JLG as an established brand of the segment before Snorkel took over the range.
For a used purchase, check the tightness of the boom and platform hydraulic cylinders, the condition of the wiring through the articulation joint, the function of the emergency lowering system, tyre condition, and the operating hours on the Deutz or Kubota engine; parts now run through Snorkel. On the older models no longer carried by Snorkel, it is also worth checking the availability of control boards, which can become a bottleneck on some model years.
Technical data
Dimensions and weights
| Length | 5,430 mmcorrect |
|---|---|
| Width | 1,750 mmcorrect |
| Ground clearance | 152.1 mmcorrect |
| Unladen weight | 6,486 kgcorrect |
| Platform length | 1,850.1 mmcorrect |
| Platform width | 1,000.3 mmcorrect |
Drivetrain and chassis
| Tyre type | poly filled / high gripcorrect |
|---|---|
| Top speed | 5.1 km/hcorrect |
Working data
| Platform capacity | 227 kgcorrect |
|---|
Electrical data
| Battery capacity | 350 Ahcorrect |
|---|---|
| Number of batteries | 8correct |
Other data
| System voltage | 48 Vcorrect |
|---|
Frequently asked questions
How much does the UpRight AB46E 2WD weigh?
The unladen weight is 6,486 kg.
How fast does the UpRight AB46E 2WD go?
Top speed is 5.1 km/h.
What are the dimensions of the UpRight AB46E 2WD?
5,430 mm × 1,750 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
