Trucksmith Limited KNEEHI
Built: 2019 · Series: Other models
More machines from model year 2019
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Trucksmith KneeHi: a class N1 low-floor van conversion with a 2,299 cm³ diesel, a 4,330 mm wheelbase and a 3,500 kg gross weight
Trucksmith Limited is an Irish commercial vehicle fit-out company that builds the KneeHi conversion range: panel vans with a lowered load-floor for more standing height inside, built onto the chassis of another maker's base vehicle. Such conversions are aimed at businesses whose staff need to stand upright in the load area without switching to a tall-roof body.
Read on 3 more paragraphs
The four-cylinder diesel engine displaces 2,299 cm³, with a 4,330 mm wheelbase and a 2,090 mm width - the dimensions of a mid-size van. Kerb weight of 2,250 kg leaves about 1,250 kg of payload against the 3,500 kg gross weight, a solid figure for a low-floor conversion, since lowering the floor itself adds little extra weight.
As a class N1 panel van, the KneeHi can be driven on a category B licence as long as the gross weight stays under 3.5 t. The lowered load floor gives extra standing height without increasing the vehicle's overall height, which benefits service vehicles and shelved fit-outs where staff enter the load area often.
When buying a used low-floor conversion, checking the lowered floor structure for through-rust and for properly executed welds at the join with the original underbody matters most. Ground clearance in the lowered section is less than on the standard vehicle, so the underbody should also be checked for damage from scraping the ground.
Sources: SpecCodex-Register: Kennwerte des Modells KNEEHI
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,299 cm³correct |
Dimensions and weights
| Width | 2,090 mmcorrect |
|---|---|
| Wheelbase | 4,330 mmcorrect |
| Unladen weight | 2,250 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
How much does the Trucksmith Limited KNEEHI weigh?
The unladen weight is 2,250 kg.
What is the gross vehicle weight of the Trucksmith Limited KNEEHI?
3,500 kg.
What engine does the Trucksmith Limited KNEEHI have?
4 cylinders, 2,299 cm³ displacement.
When was the Trucksmith Limited KNEEHI built?
Production years: 2019.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
