Terex TXC255LC-2

Series: Terex Hydraulic Excavator

Source: https://www.technikboerse.at/gebraucht/bagger-789

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex TXC255LC-2 belongs to the Terex Hydraulic Excavator series. The engine delivers 120.8 kW, has 6 cylinders, with a displacement of 5,883 cm³. Torque is 764.7 Nm. Rated speed is 2,000 rpm. The unladen weight is 24,599.7 kg. Ground clearance is 451.1 mm. The tank holds 400.1 litres. Maximum torque is reached at 1,400 rpm. The pump delivers 438.4 l/min. The hydraulic tank holds 330.1 litres. Working pressure is 323 bar. The cooling system holds 24.2 litres. The oil fill is 27.3 litres. The electrical system runs on 24 V. The engine fitted is the DL06. The Terex Hydraulic Excavator series covers 23 models. Rated output within it ranges from 70.1 to 244.6 kW; the TXC255LC-2 sits in the lower part of that range with 120.8 kW. Its immediate neighbours are the 1605LC below it with 111.9 kW and the 1604LC above it with 123 kW. 377 Terex models across 29 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelDL06correct
Power120.8 kWcorrect
Rated speed2,000 rpmcorrect
Torque764.7correct
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Displacement5,883 cm³correct
AspirationTurbocharged air-to-water intercooledcorrect
Coolant capacity24.2 lcorrect
Engine oil capacity27.3 lcorrect

Dimensions and weights

Ground clearance451.1correct
Unladen weight24,599.7 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow438.4 l/mincorrect
Hydraulic oil capacity330.1 lcorrect
Hydraulic pressure323 barcorrect
Fuel tank capacity400.1 lcorrect

Other data

Cab height2,971.8correct

More machines with this engine (Doosan DL06, 21)

Where this model stands

Power-to-weight ratio: 4.9 kW/t (121 kW / 24.6 t)

Stronger than 57% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Terex TXC255LC-2 have?

The Terex TXC255LC-2 delivers 121 kW.

How much does the Terex TXC255LC-2 weigh?

The unladen weight is 24,600 kg.

What engine does the Terex TXC255LC-2 have?

6 cylinders, 5,883 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
