Terex TR35

Series: Terex Rock Truck

Source: http://www.mascus.com.tw/construction/%B6%FE%CA%D6-%84%82%D0

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the TR35, Terex offers a model from the Terex Rock Truck series. The engine delivers 405.5 hp (275.2 kW), has 6 cylinders, with a displacement of 10,831.8 cm³. Torque is 1,898.1 Nm. Rated speed is 2,100 rpm. The machine is 8,001 mm long and 4,002 mm wide. The wheelbase measures 3,602.7 mm. Ground clearance is 502.9 mm. Top speed is 59.1 km/h. The tank holds 371.3 litres. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 121.1 litres. The cooling system holds 94.3 litres. The oil fill is 34.1 litres. The electrical system runs on 24 V. The engine fitted is the QSM11-C400E. Tyre size: 18,00-25 (32PR) E-3. The Terex Rock Truck series covers 21 models. Rated output within it ranges from 405.5 to 2,737.4 hp; the TR35 sits at the bottom of that range with 405.5 hp. Its immediate neighbours are the TR40 above it with 481.6 hp. 377 Terex models across 29 series are on record. The model is listed under Mining equipment. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model	QSM11-C400Ecorrect
Power	405.5 hp (275.2 kW)correct
Rated speed	2,100 rpmcorrect
Torque	1,898.1correct
Speed at max. torque	1,400 rpmcorrect
Cylinders	6correct
Displacement	10,831.8 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	94.3 lcorrect
Engine oil capacity	34.1 lcorrect

Dimensions and weights

Length	8,001correct
Width	4,002correct
Wheelbase	3,602.7correct
Ground clearance	502.9correct

Drivetrain and chassis

Gearbox type	Allison 4500 RDScorrect
Tyre size	18.00-25 (32PR) E-3correct
Top speed	59.1 km/hcorrect
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	121.1 lcorrect
Fuel tank capacity	371.3 lcorrect

Frequently asked questions

How much power does the Terex TR35 have?

The Terex TR35 delivers 406 hp.

What engine does the Terex TR35 have?

6 cylinders, 10,832 cm³ displacement.

How fast does the Terex TR35 go?

Top speed is 59.1 km/h.

What are the dimensions of the Terex TR35?

8,001 mm × 4,002 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
