System Trailers TFSH 18 TRPLY (8460 kg)
Built: 2010-2011 · Series: TFSH
More machines from model year 2010
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
System Trailers TFSH – flatbed trailers with plywood floor from Papenburg: unladen weight 6,900 to 8,650 kg, gross weight 25,000 to 39,000 kg, lengths up to 13,900 mm
Alongside the PRS range, System Trailers builds the independent TFSH range in Papenburg in the Emsland region. The PLYWOOD suffix in every model name shows that the loading floor of these versions is fitted with a plywood deck; the type numbers 10, 18 and 27 order the versions by size, and further suffixes such as TR and TRI mark additional build variants. The open design also allows top loading by crane, for instance for long profiles or pipes that would not fit through an end door.
Read on 3 more paragraphs
The register lists 5 versions with unladen weights from 6,900 to 8,650 kg, gross weights from 25,000 to 39,000 kg, lengths from 11,300 to 13,900 mm and a width of 2,550 mm. The entire range therefore falls into vehicle class O4.
With a plywood floor and open loading area, the TFSH range suits goods secured with straps rather than carried in a closed body, such as construction and landscaping materials, machinery or palletised goods loaded by forklift or crane from the side and from above.
When buying a used flatbed of this kind, the condition of the plywood floor for cracks, rot and sag, the lashing points and stakes, the axles and braking system, and the chassis for corrosion matter; on the multi-axle versions, even wear across all axles also matters. Spare parts and service run directly through the manufacturer.
Sources: SpecCodex register, model data: System Trailers TFSH
Technical data
Dimensions and weights
| Length | 13,900 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 8,910 mmcorrect |
| Unladen weight | 8,460 kgcorrect |
| Gross vehicle weight | 33,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the System Trailers TFSH 18 TRPLY weigh?
The unladen weight is 8,460 kg.
What is the gross vehicle weight of the System Trailers TFSH 18 TRPLY?
33,000 kg.
Up to what speed is the System Trailers TFSH 18 TRPLY approved?
Approved up to 100 km/h.
What are the dimensions of the System Trailers TFSH 18 TRPLY?
13,900 mm × 2,550 mm.
When was the System Trailers TFSH 18 TRPLY built?
Production years: 2010-2011.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
