Steyr Daimler Puch (SDP) 8165 a
Built: 1986–1993 · Series: 80er-Baureihe
More machines from model year 1986
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
8165 a (80er-Baureihe series) by Steyr Daimler Puch (SDP): six-cylinder diesel engine rated at 110.4 kW (150 hp), built between 1986 and 1993.
Under the Steyr Daimler Puch (SDP) brand, the 1980s 80er-Baureihe covered the Austrian maker's upper power segment, before the tractor division became the independent company Steyr-Landmaschinen.
Read on 3 more paragraphs
The 8165 a is powered by a six-cylinder diesel engine of 6,596 cm³ displacement, delivering 110.4 kW (150 hp) at 2,200 rpm. At an unladen weight of 5,575 kg, a wheelbase of 2,720 mm and a top speed of 30 km/h, the tractor is a strong representative of the upper mid-class of those years, at a ratio of roughly 50 kg of weight per kW of engine output.
Six-cylinder tractors of this power class handled heavy soil cultivation in the 1980s through the three-point linkage to ISO 730 and drove large implements through the 540 or 1,000 rpm power take-off, from heavy ploughs to large disc harrows, seed drills and forage trailers on bigger fields. The 30 km/h top speed limit was standard for this vehicle class and geared mainly toward field work rather than fast road transport between distant plots.
On a used 8165 a, it is worth checking the crankshaft and oil pan for leaks and the clutch for wear, since six-cylinder machines of this age often ran in continuous duty across many seasons. The front axle should also be closely assessed given the tractor's substantial unladen weight and years of field work.
Sources: SpecCodex-Register: Kennwerte des Modells 8165 a
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 150 hp (110.4 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,596 cm³correct |
| Bore | 108 mmcorrect |
| Stroke | 120 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,571 mmcorrect |
|---|---|
| Width | 2,490 mmcorrect |
| Height | 2,920 mmcorrect |
| Wheelbase | 2,720 mmcorrect |
| Ground clearance | 475 mmcorrect |
| Unladen weight | 5,575 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 12V/4R, 24V/8R or 36V/12Rcorrect |
| Front tyres | 14.9 R 28 AScorrect |
| Rear tyres | 20.8 R 38 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 19.8 kW/t (110 kW / 5.6 t)
Power class: Large (100–180 hp)
Stronger than 84% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Steyr Daimler Puch (SDP) 8165 a have?
The Steyr Daimler Puch (SDP) 8165 a delivers 150 hp.
How much does the Steyr Daimler Puch (SDP) 8165 a weigh?
The unladen weight is 5,575 kg.
What engine does the Steyr Daimler Puch (SDP) 8165 a have?
6 cylinders, 6,596 cm³ displacement, Diesel.
How fast does the Steyr Daimler Puch (SDP) 8165 a go?
Top speed is 30 km/h.
What are the dimensions of the Steyr Daimler Puch (SDP) 8165 a?
4,571 mm × 2,490 mm × 2,920 mm.
When was the Steyr Daimler Puch (SDP) 8165 a built?
Production years: 1986–1993.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
