Sommer SG 800 RT
Built: 1976 · Series: SG
More machines from model year 1976
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Sommer SG – the semi-trailer range from the Osnabrück manufacturer: versions from the SG 18 to the SG 800 RT, 10.1 to 13.9 m length, 4.0 to 8.76 t unladen weight and gross weight up to 35 t
The SG range denotes semi-trailers at Sommer Fahrzeugbau of Osnabrück. The versions recorded in the register reach lengths well over ten metres and gross weights up to 35 tonnes, placing them clearly in this vehicle class rather than among the manufacturer's lighter trailers. The type designations range from the SG 18 and SG 50 through the SG 100, SG 100 T and SG 160T to the SG 200 T-A, SG 240T-ATX, SG 299T and SG 800 RT; the suffixes T, AX and ATX mark different chassis and axle versions.
Read on 3 more paragraphs
The register lists 16 versions with unladen weights from 4,000 to 8,760 kg, gross weights from 8,600 to 35,000 kg, lengths from 10,100 to 13,900 mm and widths from 2,500 to 2,550 mm.
Semi-trailers of this size carry general cargo, machinery, building materials or swap bodies in long-haul transport and are pulled by tractor units of various makes; the span from just under nine to 35 tonnes gross weight covers both lighter box trailers and heavy low-loader versions.
On a used semi-trailer of this size, the condition of axles, brakes and air suspension, rust on the frame and kingpin, the tightness of the tarpaulin or box body, and tyres and underrun protection all count; a current roadworthiness report belongs in the check before purchase. The condition of the landing legs and the fifth-wheel coupling plate, along with a complete set of tyres with sufficient tread depth, also belongs in the check.
Sources: SpecCodex register, model data: Sommer SG
Technical data
Dimensions and weights
| Length | 11,800 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Wheelbase | 6,600 mmcorrect |
| Unladen weight | 4,720 kgcorrect |
| Gross vehicle weight | 11,520 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Sommer SG 800 RT weigh?
The unladen weight is 4,720 kg.
What is the gross vehicle weight of the Sommer SG 800 RT?
11,520 kg.
Up to what speed is the Sommer SG 800 RT approved?
Approved up to 100 km/h.
What are the dimensions of the Sommer SG 800 RT?
11,800 mm × 2,500 mm.
When was the Sommer SG 800 RT built?
Production years: 1976.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
