Snorkel AB46E 2WD – specifications

Series: Snorkel Boom Lift

Build year not documented · Data origin: Directory data · sources

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The AB46E 2WD is an articulating telescopic boom lift from the Snorkel Boom Lift series. The abbreviation AB stands for Articulating Boom, defining the machine type as an articulating boom lift capable of reaching over obstacles. The number 46 in the model name indicates the working height in feet. As an electric drive unit with two driven wheels, this machine is designed for use on firm, level surfaces. The manufacturer Snorkel produces these units at its facilities in Elwood and Vigo.

With a length of 5,430 mm and a width of 1,750 mm, the machine remains compact enough for tight work areas. The empty weight of 6,486 kg ensures stable stability without exerting excessive pressure on sensitive floors. The ground clearance of 152.1 mm allows for traversing minor unevenness. The platform offers sufficient space for the operator and tools with a length of 1,830.1 mm and a width of 991.1 mm. A load capacity of 227 kg permits the transport of materials. Non-marking tires prevent residues on sensitive surfaces. With 48 V onboard voltage and eight batteries of 350 Ah each, energy supply is ensured for longer duty cycles. The maximum speed of 5.8 km/h is designed for safe movement within the work environment.

Within the series, the AB46E 2WD ranks 15th out of 25 models in terms of empty weight. The next smaller model is the SP18 with a weight of 6,350 kg. The next larger model is the AB46RT 4WD with 6,650 kg. The entire range of the series spans from 2,570 kg to 18,978 kg.

Snorkel boom lifts AB, TB, M and SP – from Elwood, Kansas: AB for articulating, TB for telescopic, the number as working height in feet, J for the jib, up to the TB126J, 2.6 to 19 t

Snorkel goes back to the fire service: in 1958 the Pitman company in Kansas built the first articulated-boom firefighting unit, which became known as the 'Snorkel', and from it grew the maker of aerial work platforms that today manufactures in Elwood, Kansas, and Vigo in Spain and has belonged to the Ahern group since 2013. The type logic of the boom lifts: AB stands for Articulating Boom, the articulated telescopic lift that reaches over obstacles, TB for Telescopic Boom, the straight boom with long reach, M for the compact electric articulating lifts for indoor use, SP for the mast lifts; the number gives the working height in feet – AB38 about 38 ft, TB60 60 ft, TB126J 126 ft, i.e. a good 40 m – J marks the jib at the boom end, RT and 4x4 the rough-terrain version with all-wheel drive, E and N electric drive and the narrow layout respectively, W the wide one.

Read on 3 more paragraphs

The register lists 27 versions with service weights from 2,570 to 18,978 kg, lengths from 930 to 8,900 mm and widths from 810 to 2,603 mm – the 810 mm wide M models drive through doors, the TB120 and TB126J are the lifts for shipyards, stadiums and industrial construction.

Boom lifts are the machines for work over obstacles – façades, hall roofs, bridge undersides – where scissor lifts cannot reach; Snorkel serves above all the rental market and is strong in North America and Britain.

On used lifts, operating hours, play in boom and slew-ring bearings, the condition of hydraulic cylinders and hoses, the function of tilt and load sensors and a valid periodic inspection, without which no lift may be operated, are what count.

Sources: SpecCodex register, model data: Snorkel Auslegerbühnen, Snorkel (manufacturer)

Technical data

Dimensions and weights

Length5,430 mmcorrect
Width1,750 mmcorrect
Ground clearance152.1 mmcorrect
Unladen weight6,486 kgcorrect
Platform length1,830.1 mmcorrect
Platform width991.1 mmcorrect

Drivetrain and chassis

Tyre typenon markingcorrect
Top speed5.8 km/hcorrect
Turning radius3,000 mmcorrect

Working data

Platform capacity227 kgcorrect

Electrical data

Battery capacity350 Ahcorrect
Number of batteries8correct

Other data

System voltage48 Vcorrect

Frequently asked questions

How much does the Snorkel AB46E 2WD weigh?

The unladen weight is 6,486 kg.

How fast does the Snorkel AB46E 2WD go?

Top speed is 5.8 km/h.

What are the dimensions of the Snorkel AB46E 2WD?

5,430 mm × 1,750 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
