Siemens 1AV3137A – specifications
Series: 1AV
The 1AV3137A from Siemens is a three-phase induction motor. The rated output is 15 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The housing is frame size 132 M in foot-mounted form. The protection class is IP55. The efficiency is 91.8 per cent at full load, 92.3 per cent at 75 per cent load and 91.9 per cent at half load. The motor weighs 65 kg. At full load it delivers 48 Nm. The motor is built in Czechia. The figures come from the Australian MEPS register under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Siemens range ranges from 0.75 to 200 kW; the 1AV3137A sits at the bottom of that range with 15 kW. Its immediate neighbours are the 1AV2167B below it with 13.8 kW and the 1AV2204B above it with 18.2 kW. 569 Siemens models across 4 series are on record.
Build year not documented · Data origin: Official register · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Siemens – 1AV series at a glance
The 1AV series from Siemens comprises 71 models in the register, in the Electric motors group. Rated power ranges from 1 to 45 kW. Listed in the register: 1AV2162C, 1AV2166A, 1AV2166B, 1AV2167B.
Sources: SpecCodex-Register (eigene Daten)
Technical data
Engine
| Rated output | 15 kWcorrect |
|---|
Dimensions and weights
| Weight | 65 kgcorrect |
|---|
Electrical data
| Number of poles | 2correct |
|---|---|
| Protection class | IP55correct |
| Frame size | 132 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B6, B7, B8, B9, B10, B14, B15, B20, B25, B30, B34, B35, V1, V2, V3, V4, V5, V6, V8, V9, V10, V14, V15, V16, V18, V19, V30, V31, V36correct |
| Efficiency at full load | 91.75 %correct |
| Efficiency at 75 % load | 92.26 %correct |
| Efficiency at half load | 91.88 %correct |
Origin and approval
| Country of manufacture | Czechiacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
