Sdf Agrotron 4.70
Built: 1995–1997 · Series: Agrotron MK 1
More machines from model year 1995
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
SDF Agrotron MK1 – 4.70 and 4.80: the first Agrotron generation from 1995, built at Lauingen, 50.7 to 55.2 kW, four-cylinder engines at 3,192 cc and 3,890 to 3,970 kg
From 1995 the Agrotron was the new flagship range of the SAME Deutz-Fahr group, replacing Deutz-Fahr's earlier D-series, and it was built at the Lauingen an der Donau plant. The 4.70 and 4.80 listed here belong to the first Agrotron generation, known as the MK1, with the digit 4 in the type designation marking the range and the figures after the decimal point, 70 and 80, giving the approximate horsepower class.
Read on 3 more paragraphs
The register lists 2 variants with 50.7 to 55.2 kW of power from four-cylinder engines of 3,192 cc displacement at a rated speed of 2,300 rpm and torque of 268 to 290 Nm. Unladen weights fall between 3,890 and 3,970 kg, with dimensions of 4,005 mm in length, 2,008 mm in width and 2,720 mm in height. Both variants are approved for diesel and biodiesel operation.
The Agrotron MK1 brought a more modern cab concept and, for its era, advanced electronics compared with the D-series, positioning Deutz-Fahr in the upper mid-class segment alongside the Fendt Favorit and John Deere 6-series. The 4.70/4.80 class covered the lower power band of this new generation.
When buying used, test the electronics controlling hydraulics and the PTO, as these were new for the generation and worth checking carefully. The four-cylinder engine is regarded as solid but needs sound seals and fuel lines when run on biodiesel. Cab mounts and chassis bushings should be checked for wear; parts supply runs reliably through the Deutz-Fahr network.
Sources: SpecCodex register, model data: SDF Agrotron MK1, Deutz-Fahr (SAME Deutz-Fahr Group, Hersteller)
Technical data
Engine
| Fuel | Diesel / Biodieselcorrect |
|---|---|
| Power | 68 hp (50.7 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Torque | 268 Nmcorrect |
| Speed at max. torque | 1,380 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,192 cm³correct |
| Bore | 94 mmcorrect |
| Stroke | 115 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,005 mmcorrect |
|---|---|
| Width | 2,008 mmcorrect |
| Height | 2,720 mmcorrect |
| Wheelbase | 2,419 mmcorrect |
| Ground clearance | 475 mmcorrect |
| Unladen weight | 3,890 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 21V/7R or 24V/8Rcorrect |
| Front tyres | 13.6 R 24 AScorrect |
| Rear tyres | 16.9 R 34 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 13 kW/t (51 kW / 3.9 t)
Power class: Universal (40–100 hp)
Stronger than 47% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Sdf Agrotron 4.70 have?
The Sdf Agrotron 4.70 delivers 68 hp.
How much does the Sdf Agrotron 4.70 weigh?
The unladen weight is 3,890 kg.
What engine does the Sdf Agrotron 4.70 have?
4 cylinders, 3,192 cm³ displacement, Diesel / Biodiesel.
How fast does the Sdf Agrotron 4.70 go?
Top speed is 30 km/h.
What are the dimensions of the Sdf Agrotron 4.70?
4,005 mm × 2,008 mm × 2,720 mm.
When was the Sdf Agrotron 4.70 built?
Production years: 1995–1997.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
