Schneider Maschinen Und Traktorenbau Mo 22
Built: 1948–11/1949 · Series: Mo
More machines from model year 1948
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Schneider Mo 22: two-cylinder tractor with thermosiphon cooling, rated at 16.2 kW and 1,750 kg weight from the 1948 Mo range
The Mo 22 was built in the immediate post-war years, when smaller German engineering firms began producing simple field tractors for agriculture that needed rebuilding. Such firms often made tractors in small numbers, meant chiefly to replace horse teams on smaller farms.
Read on 3 more paragraphs
The Mo 22 is powered by a two-cylinder engine of 2,040 cc with thermosiphon water cooling, producing 16.2 kW (22 hp) at 1,300 rpm. At a weight of 1,750 kg and a width of 1,600 mm, the tractor reaches a design top speed of 19 km/h. Height stands at 2,000 mm and length at 2,700 mm. The engine runs on diesel.
A two-cylinder of this power class with simple thermosiphon cooling and no water pump marks a light field tractor of the immediate post-war years, built for smaller mixed farms growing cereals and root crops. The 19 km/h top speed falls within today's L driving licence category, and four-wheel drive was not yet a feature of machines in this class.
A vehicle this old and built in such small numbers is today found mainly as a collector's or museum piece. At inspection, the completeness of original parts, the condition of the thermosiphon cooling and any rust damage to the sheet metal count among the most important points, along with the availability of spare parts and documentation for such a rarely built tractor.
Sources: SpecCodex-Register: Kennwerte des Modells Mo 22
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 22 hp (16.2 kW)correct |
| Rated speed | 1,300 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 2,040 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,700 mmcorrect |
|---|---|
| Width | 1,600 mmcorrect |
| Height | 2,000 mmcorrect |
| Unladen weight | 1,750 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4V+1Rcorrect |
| Front tyres | 5.50-19correct |
| Rear tyres | 8, 00-20 oder 9, 00-24correct |
| Top speed | 19 km/hcorrect |
Origin and approval
| Construction | frameless unit constructioncorrect |
|---|---|
| Units built | ca. 25 * Schneider I. In:correct |
Where this model stands
Power-to-weight ratio: 9.3 kW/t (16 kW / 1.8 t)
Power class: Compact (< 40 hp)
Stronger than 9% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Schneider Maschinen Und Traktorenbau Mo 22 have?
The Schneider Maschinen Und Traktorenbau Mo 22 delivers 22 hp.
How much does the Schneider Maschinen Und Traktorenbau Mo 22 weigh?
The unladen weight is 1,750 kg.
What engine does the Schneider Maschinen Und Traktorenbau Mo 22 have?
2 cylinders, 2,040 cm³ displacement, Diesel.
How fast does the Schneider Maschinen Und Traktorenbau Mo 22 go?
Top speed is 19 km/h.
What are the dimensions of the Schneider Maschinen Und Traktorenbau Mo 22?
2,700 mm × 1,600 mm × 2,000 mm.
When was the Schneider Maschinen Und Traktorenbau Mo 22 built?
Production years: 1948–11/1949.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
