Scania 164 LA 6X2/2 NA

Built: 2004 · Series: R

More machines from model year 2004

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 164 LA 6X2/2 NA, Scania offers a model from the R series. Production: 2004. The engine has 8 cylinders. The machine is 5,970 mm long and 2,540 mm wide. The unladen weight is 8,260 kg. The wheelbase measures 3,700 mm. The gross vehicle weight is 23,500 kg. The machine runs on 6 wheels. The R series covers 1736 models. Unladen weight within it ranges from 6,580 to 76,711 kg; the 164 LA 6X2/2 NA sits at the bottom of that range with 8,260 kg. Its immediate neighbours are the 500 LA 6X2/4 MNB below it with 8,250 kg and the 3M6X2/4 AS 70180 above it with 8,270 kg. Gross vehicle weight within it ranges from 10,000 to 76,961 kg; here the 164 LA 6X2/2 NA sits in the lower part of that range with 23,500 kg. 11893 Scania models across 91 series are on record.

Scania R — the letter is the cab, not the engine

Scania's R says nothing about engine or weight. It names the cab. Scania grades its cabs by height and entry: P is the low one, G the medium, R the tall long-haul cab, S the tallest with a flat floor and no engine tunnel. Anyone looking for an R is therefore looking first for a place to live in — long haul, overnight stays, standing room.

Read on 4 more paragraphs

The number after it is engine output in horsepower. An R 450 has 450 hp, an R 500 has 500. Read together, the designation is cab plus power — unlike MAN or Mercedes, where the first number means gross vehicle weight. Anyone comparing offers across brands should know this difference, or they will be comparing weight against power.

A suffix such as A4x2NA or B6x4HZ often follows. The first letter gives the body type (A = tractor unit, B = platform chassis), the digits the axle configuration, the final letters the suspension — N for air, H for leaf springs on the rear axle. That suffix often says more about a used vehicle's suitability than the horsepower figure does.

Important when searching: two vehicle generations share the letter. The R-series of 2004 was followed in 2016 by the next generation, developed internally as the New Truck Generation. Both are simply called R in listings. Two vehicles with identical designations can therefore be twelve years of development apart — what decides is first registration and emissions standard, not the letter.

Further back, Scania trucks carried plain numbers: 113, 143, 164. There the first digit stood for displacement in litres and the last for the series, so 113 meant eleven litres from the 3-series. That reading no longer applies to the R — but it explains why both systems appear side by side in used listings.

Sources: Scania Group, Wikipedia: Scania 3-series (Wikipedia), Fleet News

Technical data

Engine

Cylinders8correct

Dimensions and weights

Length5,970 mmcorrect
Width2,540 mmcorrect
Wheelbase3,700 mmcorrect
Unladen weight8,260 kgcorrect
Gross vehicle weight23,500 kgcorrect

Drivetrain and chassis

Wheels6correct

Frequently asked questions

How much does the Scania 164 LA 6X2/2 NA weigh?

The unladen weight is 8,260 kg.

What is the gross vehicle weight of the Scania 164 LA 6X2/2 NA?

23,500 kg.

What engine does the Scania 164 LA 6X2/2 NA have?

8 cylinders.

What are the dimensions of the Scania 164 LA 6X2/2 NA?

5,970 mm × 2,540 mm.

When was the Scania 164 LA 6X2/2 NA built?

Production years: 2004.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
