SAME Lamborghini Hürlimann H-361 (A)

Built: 1986–1997 · Series: H-Baureihe

More machines from model year 1986

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The SAME Lamborghini Hürlimann H-361 (A) belongs to the H series. Production: 1986–1997. The engine delivers 60 hp (44.1 kW), has 3 cylinders, with a displacement of 3,116 cm³. Torque is 195 Nm. Rated speed is 2,200 rpm. The machine is 3,440 mm long, 1,760 mm wide and 2,375 mm high. The unladen weight is 2,425 kg. The wheelbase measures 2,085 mm. Ground clearance is 335 mm. Top speed is 30 km/h. Transmission: 12V/3R or 16V/3R. The engine is air-cooled. Tyres: front 7.50-16 ASF (A: 9.5-24 AS), rear 14.9-30 AS. The fuel is diesel. The bore measures 98 mm. The stroke is 120 mm. The compression ratio is 17:1. Maximum torque is reached at 1,412 rpm. Construction: unit construction (no separate frame). Injection pressure is 210 bar. The H-Baureihe series covers 26 models. Rated output within it ranges from 48 to 200 hp; the H-361 (A) sits at the bottom of that range with 60 hp. Its immediate neighbours are the H-355 (A) below it with 58 hp and the H-360 (A) above it with 62 hp. Unladen weight within it ranges from 1,980 to 8,500 kg; here the H-361 (A) sits at the bottom of that range with 2,425 kg. 54 SAME Lamborghini Hürlimann models across 9 series are on record.

Hürlimann H series: Swiss mountain engineering within the SLH group, from the D-470 (A) to the H-362 (A), 35.3 to 147.2 kW, three- to six-cylinder engines with air or water cooling

In 1979 SAME took over Swiss tractor builder Hürlimann, and together with Lamborghini, acquired back in 1973, formed the SAME-Lamborghini-Hürlimann (SLH) group. The H series bundles the models carried under the Hürlimann badge from this era, known for chassis engineering built for mountain and slope work.

Read on 4 more paragraphs

The register lists 26 live models, from the D-470 (A) to the H-362 (A), built between 1979 and 2003. Output ranges from 35.3 to 147.2 kW, weight from 1,980 to 8,500 kg, displacement from 2,714 to 7,480 cm3, across three- to six-cylinder engines.

Characteristic of Hürlimann tractors from this period are standard four-wheel drive, a compact build height and a chassis tuned for Swiss terrain — the brand was already among the industry's 4WD pioneers even before the SLH era.

In 1995 the group also acquired Deutz-Fahr and has traded as SAME Deutz-Fahr (SDF) ever since — still the parent brand under which Hürlimann continues today.

Within the H series, the cooling method changes with engine size: the smaller two- and three-cylinder models ran air cooling, the larger four- to six-cylinder units water cooling – a sign that very different machines hide behind the same series name. When buying used, it is worth establishing the cooling method of the specific model first, since servicing and spares – a cooling fan here, a radiator and water pump there – differ fundamentally.

Sources: SpecCodex register, model data: Hürlimann H-Baureihe

Technical data

Engine

Fuel	dieselcorrect
Power	60 hp (44.1 kW)correct
Rated speed	2,200 rpmcorrect
Torque	195 Nmcorrect
Speed at max. torque	1,412 rpmcorrect
Cylinders	3correct
Displacement	3,116 cm³correct
Bore	98 mmcorrect
Stroke	120 mmcorrect
Compression ratio	17correct
Injection pressure	210 barcorrect
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,440 mmcorrect
Width	1,760 mmcorrect
Height	2,375 mmcorrect
Wheelbase	2,085 mmcorrect
Ground clearance	335 mmcorrect
Unladen weight	2,425 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	12V/3R or 16V/3Rcorrect
Front tyres	7.50-16 ASF (A: 9.5-24 AS)correct
Rear tyres	14.9-30 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 18.2 kW/t (44 kW / 2.4 t)

Power class: Universal (40–100 hp)

Stronger than 41% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the SAME Lamborghini Hürlimann H-361 (A) have?

The SAME Lamborghini Hürlimann H-361 (A) delivers 60 hp.

How much does the SAME Lamborghini Hürlimann H-361 (A) weigh?

The unladen weight is 2,425 kg.

What engine does the SAME Lamborghini Hürlimann H-361 (A) have?

3 cylinders, 3,116 cm³ displacement, Diesel.

How fast does the SAME Lamborghini Hürlimann H-361 (A) go?

Top speed is 30 km/h.

What are the dimensions of the SAME Lamborghini Hürlimann H-361 (A)?

3,440 mm × 1,760 mm × 2,375 mm.

When was the SAME Lamborghini Hürlimann H-361 (A) built?

Production years: 1986–1997.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
