SAME Deutz Fahr H-56 XA
Built: 2005–2014 · Series: Dritte XA-Baureihe
More machines from model year 2005
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hürlimann XA third generation: the newest compact class, from the H-56 XA to the H-100 XA, 40.4 to 69.8 kW (55 to 95 hp), three- and four-cylinder engines with water cooling
As the third generation of the XA series, this range carries the Hürlimann tradition of compact tractors within the SDF group into the 2010s, with reworked technology compared with earlier XA generations.
Read on 4 more paragraphs
The register lists 6 live models, from the H-56 XA to the H-100 XA, built between 2005 and 2014. Output ranges from 40.4 to 69.8 kW, or 55 to 95 hp, weight from 2,550 to 3,300 kg, displacement from 3,000 to 4,000 cm3, across three- and four-cylinder engines.
Compared with the previous XA generation, the third iteration extended peak output up to 95 hp with the H-100 XA, covering a somewhat wider field within the compact Hürlimann class.
Since several XA generations with similar type designations coexist in the register, the exact build year is decisive when buying used, to correctly identify the generation.
In this weight range of roughly 2.5 to 3.3 tonnes, the PTO is normally built to the standard speed of 540 rpm for this class, with the three-point linkage to ISO 730 usually in Category I or II – enough for the common implements on grassland and specialty-crop holdings. Since Hürlimann has shared drivetrain components with other group brands since the SLH era and later under SDF, spares for the third XA generation today run through the shared SDF group-wide dealer network.
Sources: SpecCodex register, model data: Hürlimann XA (dritte Generation)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 55 hp (40.4 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 240 Nmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 3,000 cm³correct |
| Bore | 105 mmcorrect |
| Stroke | 115.5 mmcorrect |
| Compression ratio | 17correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,405 mmcorrect |
|---|---|
| Width | 1,920 mmcorrect |
| Height | 2,375 mmcorrect |
| Wheelbase | 2,056 mmcorrect |
| Ground clearance | 410 mmcorrect |
| Unladen weight | 2,550 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 20V/10Rcorrect |
| Front tyres | 320/70 R 20 AScorrect |
| Rear tyres | 420/70 R 30 AScorrect |
| Top speed | 40 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 15.8 kW/t (40 kW / 2.5 t)
Power class: Universal (40–100 hp)
Stronger than 38% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the SAME Deutz Fahr H-56 XA have?
The SAME Deutz Fahr H-56 XA delivers 55 hp.
How much does the SAME Deutz Fahr H-56 XA weigh?
The unladen weight is 2,550 kg.
What engine does the SAME Deutz Fahr H-56 XA have?
3 cylinders, 3,000 cm³ displacement, Diesel.
How fast does the SAME Deutz Fahr H-56 XA go?
Top speed is 40 km/h.
What are the dimensions of the SAME Deutz Fahr H-56 XA?
3,405 mm × 1,920 mm × 2,375 mm.
When was the SAME Deutz Fahr H-56 XA built?
Production years: 2005–2014.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Sources: Wikibooks Traktorenlexikon (CC BY-SA 4.0) (retrieved August 2026) · Values adopted and presented in our own form; changes from the source are possible. · How we check the data
