S&l YE2-160M2-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
S&L – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, Y2VP and YE2 scheme, frame sizes 90 to 280, 1.1 to 75 kW, 2- to 6-pole
This page gathers the S&L three-phase motors the Australian energy-efficiency register could not assign to a named range. S&L is a Chinese maker of three-phase motors for the Australia-Pacific market. The designations in the register split across two ranges: Y2VP, with the larger frame sizes from 160 up, and YE2, a standard range widespread in China for three-phase motors with raised efficiency, with the smaller and medium frame sizes.
Read on 3 more paragraphs
The register lists here 20 versions with 1.1 to 75 kW, two- to six-pole, full-load efficiencies from 78.46 to 94.49% and at 75% load from 77.82 to 94.74%. Frame sizes run from 90 to 280, supply voltage is uniformly 415 V, protection is consistently IP55. Manufacturing is exclusively in China, testing followed the 2019 GEMS determination with test methods A and 2-1-1B; none of the 20 motors reaches a High Efficiency Level.
With the combination of the Y2VP and YE2 ranges, S&L serves the mid to upper power segment of the Australian market for IEC standard motors, competing with numerous other Chinese suppliers for pumps, fans and conveyors.
When buying used, bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with range, frame size and pole count matter; on the larger Y2VP frame sizes from 250 up, the lifting eyes and foundation fixing are also worth a look. Spares run through the distribution for Chinese standard motors.
Sources: SpecCodex register, model data: S&L (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 15 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 160Mcorrect |
| Mounting (IEC 60034-7) | B3, B35correct |
| Efficiency at full load | 90.67 %correct |
| Efficiency at 75 % load | 89.95 %correct |
| Efficiency at half load | 87.56 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 61972correct |
Frequently asked questions
How much power does the S&l YE2-160M2-2 have?
The S&l YE2-160M2-2 delivers 15 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
