Rxm Electric Motor 90
Series: Other models
RXM Electric Motor – other models: the collective page for three-phase motors named by frame size outside the named series, frame sizes 80 to 250, 0.75 to 55 kW, two- to six-pole, foot mounting throughout
This page gathers three-phase motors from the manufacturer RXM Electric Motor that the register does not assign to a named series. Unusually for this collective page, the models carry no individual type designations but are simply named by IEC frame size, from 80 through 132 to 250. This range therefore covers, on a single collective page, the entire span from the smallest to the largest frame format registered here.
Read on 3 more paragraphs
The register lists 10 versions with 0.75 to 55 kW rated output, two- to six-pole, at a uniform supply voltage of 400 V. Full-load efficiency ranges from 72.8 to 93%, and at 75% load from 69.2 to 92.49%. Frame sizes span 80 to 250, and the protection class is IP55 throughout.
The unusually broad span of frame size and power within a single range covers practically the entire market spectrum of classic industrial three-phase motors, from small workshop drives to mid-sized industrial motors. Registration under the older AS/NZS 1359.5:2000 standard shows that this broad model range was certified before the later GEMS determinations.
For a replacement within this broad range, the exact match of power, frame size and pole count to the respective application matters most. The uniform B3 mounting code at least simplifies the mechanical fixing, regardless of the frame size chosen within the range.
Sources: SpecCodex register, model data: RXM Electric Motor (weitere Modelle), Zulassungsdaten GEMS/MEPS (Australien, Neuseeland)
Technical data
Engine
| Rated output | 0.75 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 6correct |
| Protection class | IP55correct |
| Frame size | 90 S (foot)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 72.8 %correct |
| Efficiency at 75 % load | 69.2 %correct |
| Efficiency at half load | 62.2 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2000 (Legacy)correct |
|---|---|
| Test method | AS 1359.102.1:1997correct |
Frequently asked questions
How much power does the Rxm Electric Motor 90 have?
The Rxm Electric Motor 90 delivers 0.8 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
