Rolls Royce Solutions 12V2000G85 TB 3D
Built: 2012 · Series: 12V2000G85
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Rolls-Royce Solutions 12V2000G85 – twelve-cylinder V diesel engine from mtu in Friedrichshafen: EPA nonroad certification, 809 to 890 kW, higher-rated generator version, Tier 2, model years 2012 to 2020
Rolls-Royce Solutions runs the mtu Series 2000 range, whose large diesel engines are built in Friedrichshafen on Lake Constance in southern Germany. The 12V2000G85 designation is the twelve-cylinder V version of this range in a generator variant tuned to a higher output than the G45 type, at the same cylinder count and basic dimensions. This page gathers the 12V2000G85 versions listed in the EPA register.
Read on 3 more paragraphs
The register lists here five versions (12V2000G85, 12V2000G85 TB 3B, 12V2000G85 TB 3D, 12V2000G85 TD 3B, 12V2000G85 TD 3D) with 809 to 890 kW rated output at a constant 1,800 rpm, as a twelve-cylinder V engine with 130 mm bore and 150 mm stroke. The turbocharger is a waste-gate design, injection is direct, and the specified fuel is low-sulphur diesel at 300 to 500 ppm sulphur. The range is certified to Tier 2, for model years 2012 to 2020; maximum torque ranges from 4,292 to 4,721 Nm at 1,800 rpm.
With its higher power step, the 12V2000G85 serves larger stationary and mobile generator sets, for example for hospitals, data centres and large industrial plants with high backup demands; mtu competes here with Caterpillar, MAN and Cummins for large-genset applications.
On a used purchase, actual operating hours matter, since standby generator sets in this power class often run only in testing or emergency duty; also important are the condition of the waste-gate turbocharger, the tightness of the charge-air ducting, the cooling system and generator coupling, and a complete service record through mtu or Rolls-Royce service.
Sources: SpecCodex register, model data: Rolls-Royce Solutions 12V2000G85 (mtu Series 2000)
Technical data
Engine
| Engine code | 7,056correct |
|---|---|
| Engine family | DMDDL35.8GRR; EMDDL35.8GRR; FMDDL35.8GRR; CMDDL35.8GRR; GMDDL35.8GRRcorrect |
| Engine families | DMDDL35.8GRR; EMDDL35.8GRR; FMDDL35.8GRR; CMDDL35.8GRR; GMDDL35.8GRRcorrect |
| Fuel | 300-500 ppm Low Sulfur Dieselcorrect |
| Rated output | 890 kWcorrect |
| Power band | 560<kW<=2237correct |
| Rated speed | 1,800 rpmcorrect |
| Maximum torque | 4,721 N·mcorrect |
| Speed at max. torque | 1,800 rpmcorrect |
| Cylinders | 12correct |
| Cylinder layout | V layoutcorrect |
| Bore | 130 mmcorrect |
| Stroke | 150 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | wastegate turbochargercorrect |
| Charge-air cooling | bothcorrect |
| Emissions stage | Tier 2correct |
Origin and approval
| Version | 7,056correct |
|---|---|
| Built from | 2012correct |
| Built to | 2016correct |
| Model year from | 2012correct |
| Model year to | 2016correct |
Frequently asked questions
How much power does the Rolls Royce Solutions 12V2000G85 TB 3D have?
The Rolls Royce Solutions 12V2000G85 TB 3D delivers 890 kW.
When was the Rolls Royce Solutions 12V2000G85 TB 3D built?
Production years: 2012.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
