Rino PL4403
Built: 2012 · Series: Other models
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Rino – other models: the collective page of Dutch low-loader trailers outside the named ranges, semi low-loaders with sliding curtains, 24 to 48 tonnes gross weight, up to 17.55 metres in length
This page gathers the Rino trailers the register could not assign to a named range. Rino builds heavy low-loader and semi-low-loader trailers, described in the Dutch register in some cases directly as "semi dieplader met schuifzeilen" – a semi low-loader with sliding curtains. Type designations such as PL4803 KS, SV4503 or MP 45 03 combine letters for body and curtain variant with numbers for axle count and payload class.
Read on 3 more paragraphs
The register lists here 22 versions with unladen weights from 4,810 to 10,960 kg, gross weights from 24,000 to 48,000 kg, lengths from 6,740 to 17,550 mm and widths from 2,540 to 2,700 mm.
Low-loaders of this size carry construction machinery, agricultural equipment and special loads that would exceed the load height of a normal semi-trailer; the sliding curtain allows side loading by crane or forklift without removing the curtain entirely. Some versions additionally feature an extendable frame that adapts the load length to the cargo, for instance turbine blades or bridge girders.
On used low-loaders, the condition of frame and loading deck, ramps and locks, axles, steering axles and brakes, and the condition and function of the sliding curtain and lashing straps all count; parts run through specialist low-loader workshops. The hydraulic system for a hydraulically lowered bed, where fitted, should also be tested for leaks and even lowering on both sides.
Sources: SpecCodex register, model data: Rino (weitere Modelle), Zulassungsdaten RDW (Niederlande)
Technical data
Dimensions and weights
| Length | 13,050 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 8,910 mmcorrect |
| Unladen weight | 7,980 kgcorrect |
| Gross vehicle weight | 44,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Rino PL4403 weigh?
The unladen weight is 7,980 kg.
What is the gross vehicle weight of the Rino PL4403?
44,000 kg.
Up to what speed is the Rino PL4403 approved?
Approved up to 100 km/h.
What are the dimensions of the Rino PL4403?
13,050 mm × 2,550 mm.
When was the Rino PL4403 built?
Production years: 2012.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
