Renders RZOC 12.20 E
Built: 1999-2004 · Series: RZOC
More machines from model year 1999
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renders RZOC – agricultural tipping trailer range from the Belgian manufacturer: 20,000 to 39,000 kg gross weight, 5,880 to 25,600 kg unladen weight, 8.8 to 14.0 m length
This page gathers the RZOC range from the Belgian manufacturer Renders of Sint-Katelijne-Waver, which specialises in agricultural tipping trailers. The models from RZOC 12 24 to Rzoc 16.20 use the first number to give the axle-load or size class, the second the length or payload step of the tipping body, while NA and E mark equipment variants.
Read on 4 more paragraphs
The register lists here 10 versions with unladen weights from 5,880 to 25,600 kg, gross weights from 20,000 to 39,000 kg, lengths from 8,820 to 14,020 mm and widths from 2,500 to 2,600 mm.
Tipping trailers of the RZOC range count among the heavy agricultural trailers used in Belgian and Dutch arable farming for harvest and earth transport behind powerful tractors, where the reinforced frame construction and high payloads allow driving on unmade ground.
Agricultural tipping trailers in this weight class above 10 tonnes fall into EU class O4 with air brakes and driving licence category CE, or category T for purely field use at limited speed. The range from two to twelve wheels covers single-axle to four-axle trailers, with wide agricultural tyres and tandem or tridem axles on an equalising walking beam reducing ground pressure on unmade surfaces.
On a used trailer, the condition of the tipping body and hydraulic ram, the tightness of the side boards, corrosion of the frame and body from moisture and soil, the braking system and axles, and the tyres with an eye to agricultural-tyre wear all count; parts run through Renders itself and the agricultural specialist trade.
Sources: SpecCodex register, model data: Renders RZOC
Technical data
Dimensions and weights
| Length | 13,800 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 9,100 mmcorrect |
| Unladen weight | 25,240 kgcorrect |
| Gross vehicle weight | 32,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Renders RZOC 12.20 E weigh?
The unladen weight is 25,240 kg.
What is the gross vehicle weight of the Renders RZOC 12.20 E?
32,000 kg.
Up to what speed is the Renders RZOC 12.20 E approved?
Approved up to 100 km/h.
What are the dimensions of the Renders RZOC 12.20 E?
13,800 mm × 2,550 mm.
When was the Renders RZOC 12.20 E built?
Production years: 1999-2004.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
