Renault Ares 546 RX – specifications
Series: Other models
The Renault Ares 546 RX is a machine built by Renault. The engine delivers 87 hp (65 kW), has 4 cylinders, with a displacement of 4,525 cm³. Torque is 345 Nm. Rated speed is 2,200 rpm. The machine is 6,150 mm long, 2,550 mm wide and 2,945 mm high. The wheelbase measures 2,564 mm. Top speed is 40 km/h. The tank holds 170 litres. Transmission: 32 V/ 32 R. The engine is water-cooled. The model was built in France. The fuel is diesel. The gearbox offers 32 forward gears. The linkage is category II. The PTO runs at 540/1000 rpm. Rated output across the Renault range ranges from 15 to 250 hp; the Ares 546 RX sits in the lower part of that range with 87 hp. Its immediate neighbours are the Cergos below it with 85 hp and the Ares 546 RX/RZ above it with 90 hp. Rated output across the Renault range ranges from 11 to 184 kW; here the Ares 546 RX sits in the lower part of that range with 65 kW. 3632 Renault models across 98 series are on record.
Build year not documented · Data origin: Reference work (Wikipedia/Wikibooks) · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renault – other models: the collective page of French tractors outside the named ranges, from the D and N types through the 651 to 981 ranges to Ceres, Ares and Celtis, 11 to 166 kW, MWM, Deutz and Perkins engines
This page gathers the Renault tractors the register could not assign to a named range – from early post-war models to the ranges shortly before the takeover by Claas in 2003. Renault Agriculture, which emerged from the farm-machinery division of the car maker founded in 1920, built its tractors in Le Mans, France. The type logic changed several times: the D and N types of the 1950s and 1960s (D22, D35, N72) were small, simple utility tractors; the three-digit 651 to 981 ranges of the 1970s and 1980s order the power class in ascending order, -4 marks four-wheel-drive models and (S) the synchro-gearbox version. From the 1990s came ranges with names instead of numbers – Ceres (mid-range), Cergos, Ares (large and mid-range), Atles (big tractors), Celtis (compact class) and Pales and the narrow-track Fructus and Multis models for vineyards and orchards.
Read on 3 more paragraphs
The register lists here 66 versions with 11 to 166.3 kW from two- to six-cylinders of 1,810 to 7,146 cm³, unladen weights from 1,400 to 9,690 kg, lengths from 3,000 to 6,641 mm, widths from 1,220 to 2,550 mm and torque from 113 to 505 Nm at 2,150 to 2,350 rpm; the engines come among others from MWM, Deutz, John Deere, Perkins and Mitsubishi.
For decades Renault was, alongside Massey Ferguson, one of the leading tractor brands in France and strongly represented in viticulture, for which the narrow-track Fructus and Multis ranges were developed; after the 2003 takeover by Claas the models continued for a time under the Renault name before the brand was replaced by Claas by 2005.
On used tractors, engine and clutch condition count on the older D and numbered ranges, electronics, hydraulics and cab-mounting condition on the named ranges of the 1990s, and wear on steering and lift linkage from working between vine rows on the narrow-track vineyard models; parts now run through the Claas network.
Sources: SpecCodex register, model data: Renault (weitere Modelle), Claas (Rechtsnachfolger von Renault Agriculture)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 87 hp (65 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 345 Nmcorrect |
| Cylinders | 4correct |
| Displacement | 4,525 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 6,150 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Height | 2,945 mmcorrect |
| Wheelbase | 2,564 mmcorrect |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Gearbox | 32 V/ 32 Rcorrect |
| Forward gears | 32correct |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 170 lcorrect |
|---|
Origin and approval
| Plant | Francecorrect |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Frequently asked questions
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
