Renault Cergos 340
Built: 12/1996–1/2001 · Series: CERGOS-Baureihe
More machines from model year 1996
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renault Cergos 340 (1996-2001): water-cooled four-cylinder standard tractor with 62.6 kW output and 297 Nm of torque from the CERGOS series
The Cergos 340 was built between December 1996 and January 2001 as part of the CERGOS series and belonged to the mid-range standard tractors in Renault's 1990s programme.
Read on 3 more paragraphs
The water-cooled four-cylinder engine displaces 3,920 cm³ and delivers 62.6 kW at 2,350 rpm, equivalent to 85 horsepower, with 297 Nm of torque. With a weight of 4,255 kg, a wheelbase of 2,590 mm and a top speed of 30 km/h, the Cergos 340 was built for drawbar work in the mid power range.
Four-cylinder engines of nearly four litres displacement and about 85 horsepower formed the backbone of standard tractor fleets on medium-sized arable farms in the 1990s, powerful enough for tillage with towed implements and for driving power-take-off harvesting machinery. The top speed of 30 km/h was within the usual range at the time for road transport between farmyard and field.
When buying a used Cergos 340, the cooling system and turbocharger should be checked for leaks, since these components quickly lose performance if neglected. The hydraulic connections for implements and the condition of the three-point linkage also deserve close inspection, as they suffer heavy wear under intensive agricultural use. A test drive with an implement attached further shows whether the power take-off clutch still engages cleanly and without slipping.
Sources: SpecCodex-Register: Kennwerte des Modells Cergos 340
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 85 hp (62.6 kW)correct |
| Rated speed | 2,350 rpmcorrect |
| Torque | 297 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,920 cm³correct |
| Bore | 106.5 mmcorrect |
| Stroke | 110 mmcorrect |
| Compression ratio | 17.6correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,280 mmcorrect |
|---|---|
| Width | 2,110 mmcorrect |
| Height | 2,760 mmcorrect |
| Wheelbase | 2,590 mmcorrect |
| Ground clearance | 420 mmcorrect |
| Unladen weight | 4,255 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 18 V/18 R or 20 V/20 Rcorrect |
| Front tyres | 400/70 R 24 AScorrect |
| Rear tyres | 500/70 R 34 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 140 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 613correct |
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 14.7 kW/t (63 kW / 4.3 t)
Power class: Universal (40–100 hp)
Stronger than 58% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Renault Cergos 340 have?
The Renault Cergos 340 delivers 85 hp.
How much does the Renault Cergos 340 weigh?
The unladen weight is 4,255 kg.
What engine does the Renault Cergos 340 have?
4 cylinders, 3,920 cm³ displacement, Diesel.
How fast does the Renault Cergos 340 go?
Top speed is 30 km/h.
What are the dimensions of the Renault Cergos 340?
4,280 mm × 2,110 mm × 2,760 mm.
When was the Renault Cergos 340 built?
Production years: 12/1996–1/2001.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
